The ThermoView TV30 series from Fluke Process Instruments now offers two powerful thermal camera options: an edge sensor for standalone operation and a GigE version for advanced PC-based analysis.

Fluke Process Instruments extends its ThermoView TV30 series, launching a GigE thermographic camera in addition to the spearhead standalone version. The infrared cameras for fixed installation enable 24/7 thermal monitoring of processes and assets. They identify temperature anomalies and send alerts, allowing plant staff to rectify any problems early on and avoid poor quality output and damage to products and equipment.
The standalone version with onboard analytics and remote setup via web browser needs no PC in the field to automatically monitor up to 32 values for user-specified Areas of Interest (AOI) and criteria (max./min., average, spot temperature, standard deviation).
The GigE version was designed to meet the most sophisticated requirements. It enables direct communication between programmers and the camera using standard applications like Labview or Matlab or the proprietary ThermoView software. It connects to a shop-floor or control-room PC and can stream thermal images at up to 60 frames per second. The ThermoView software provides an extensive array of features and functions for all typical industrial temperature monitoring and documentation needs. It supports an unlimited number of AOI, trending for those AOI and manual or automated archiving of images as well as measured values for traceability.
The thermal imagers can detect temperatures from -10 °C to 1300 °C (14 °F to 2372 °F). For improved accuracy, users can specify tighter temperature ranges. The imagers feature a rugged, IP67-rated housing. The series also provides a choice of two infrared camera resolution options, three lenses for different fields of view and protective accessories for demanding environments. All versions boast excellent connectivity, with multiple supported protocols for easy integration in plant-level automation systems and computerized maintenance management systems (CMMS).

More information: https://www.flukeprocessinstruments.com/thermoview-tv30

The two technology companies have cooperated to perfect their solution for autonomous robotic acoustic inspection in industrial facilities. Boston Dynamics has named Fluke Process Instruments a Certified Technology Provider, recognizing the company’s contribution to mobile acoustic inspection technology. Fluke Process Instruments has enabled its SV600 Fixed Acoustic Imager for integration as a payload in Boston Dynamics’ agile mobile robot Spot. One main application for the smart combo is the detection of compressed air and gas leaks in industrial plants. Users have reported savings from reduced compressed air leaks in the range of tens of thousands of dollars per month. The manufacturers have been cooperating on making mobile sound detection capabilities available since 2021, launching a working system the same year. Recently, the companies announced the full integration of the acoustic camera payload in the versatile robot system – users can now program and remotely control acoustic measurements and inspection routes via the Spot dashboard and thus locate, analyze and remedy problems faster. This cooperation was prompted by Boston Dynamics customers who were looking to boost their service personnel’s capacities and asked the robotics company to make the sound measuring capabilities of the handheld Fluke ii900 Industrial Acoustic Imager available with Spot. The initial inquiry led to a speedy dedicated product development by the group member Fluke Process Instruments, which has meanwhile found many uses besides as a Spot payload.
The SV600 acoustic imager features 64 digital MEMS microphones, a camera and a processor. It is sensitive even above human hearing and can detect even small gas leaks in noisy industrial environments. Its functions include noise classification, frequency filtering and mapping dB values and sound intensity. Results are visualized using Fluke’s powerful SoundMap technology. Operators from various industries use the data to improve their plants’ energy efficiency and garner cost savings through reduced compressed air losses and more timely, cheaper repair.
Spot can take over from plant staff as an autonomous inspection unit, carrying out menial and repetitive tasks with utmost precision and allowing technicians to focus on repair and maintenance. The robot completes programmed tours of industrial facilities, taking measurements as often as necessary, transmitting the results remotely and instantly and alerting personnel to user-defined events. It finds its way up and down stairs and around obstacles.
Product page: https://www.flukeprocessinstruments.com/en-us/products/imaging-solutions/acoustic-imaging-solutions/sv600-fixed-acoustic-imager

In a joint webinar on robotic acoustic inspection, Boston Dynamics and Fluke Process Instruments will show how to improve the energy efficiency of industrial operations through automatic compressed air leak detection by means of the SV600 Fixed Acoustic Imager and the agile mobile robot Spot. The webinar on 31 October 2023, at 11 a.m. EDT (7 a.m. UTC) will address how acoustic imaging is used to locate gas leaks and how the four-legged robot completes autonomous inspection walkarounds through complex environments. Application experts from Boston Dynamics and Fluke Process Instruments will present use cases with significant cost savings and instruct participants on how to utilize the technology for their inspection needs. The SV600 payload detects sounds even above the human hearing range – even in noisy industrial environments. Combining sound maps with visual images, it can exactly pinpoint gas leaks.
Webinar details and registration: https://bostondynamics.com/webinars/improving-energy-efficiency-with-robotic-acoustic-inspection/

Fluke Process Instruments announces a new standalone thermal camera with onboard web server, advanced analytics and high connectivity Fluke Process Instruments has launched the new ThermoView TV30 thermal camera for factory automation and asset monitoring. The rugged, fixed-installation infrared camera measures a wide temperature range from -10 °C to 1300 °C (14 °F – 2372 °F) and provides an unrivaled scope of features and functions. The standalone camera provides full connectivity for easy integration with a PLC via OPC UA or MQTT. The new ThermoView TV30 thermal camera provides 24/7 monitoring of critical production processes or assets and real-time analysis and feedback to control systems to assure adherence to set temperature values and avoid downtimes or costly repairs. Users can program Areas of Interest (AOI) with individual tolerances and automatic alarms. The thermal camera is powered via a 24VDC power supply or Power over Ethernet. It features a remote motorized focus. Three lens options are available with narrow or wide fields of view for different working distances. The camera housing is rated IP67. The manufacturer provides a full range of accessories for mounting outside or in hot, dusty or dirty environments.

Fluke Process Instruments will be showcasing its temperature measurement solutions at the SENSOR+TEST and SMTconnect trade fairs in Nuremberg, Germany, May 9 – 11, 2023. At the SENSOR+TEST, the manufacturer will premiere the brand-new standalone thermographic camera ThermoView TV30 with an integrated web server. The new infrared camera for fixed installation is designed for 24/7 monitoring of manufacturing processes and equipment to ensure operational safety and quality compliance. It has a wide measuring range of -10 °C – 1300 °C (14 °F – 2372 °F), can be easily connected to a PLC via OPC UA or MQTT and transmits measurement data and analyses in real time. Additional solutions at the Fluke Process Instruments SENSOR+TEST booth cover virtually all industrial applications: rugged infrared sensors including explosion-proof versions, miniaturized spot pyrometers for cost-sensitive OEM measurement solutions, line scanners for thermal imaging in moving processes and a wide range of accessories for demanding industrial environments. At the SMTconnect, the team will present Datapaq systems for temperature profiling inside soldering ovens. The Datapaq Reflow Tracker range includes numerous compact solutions for all oven types and designs. The temperature profiling systems each consist of a data logger, thermal barrier, thermocouples and software. The tested and proven systems facilitate oven setup, quality control and auditing according to various standards. Contact the manufacturer Fluke Process Instruments booth numbers: SENSOR+TEST #1-341 SMTconnect #4-111

Fluke Process Instruments will present its acoustic and thermal imagers at Maintenance NEXT alongside Avular at Hall 2, Booth 106. The two manufacturers’ solutions complement one another perfectly as shown by the new working model for mobile, remote-controlled acoustic imaging. Fluke Process Instruments’ SV600 Fixed Acoustic Imager for gas leak detection is mounted on an Avular Origin One autonomous robot for easy maneuvering, which provides an efficient and safe way to inspect hard-to-access sites as well as environments that are deemed potentially unsafe for humans. The acoustic imager employs an array of sophisticated sound sensors, a camera and Fluke’s powerful SoundMap technology to detect and visualize gas leaks, allowing service personnel to repair them quickly before they incur mounting costs. The system easily integrates with factory systems and enables 24/7 monitoring of compressors, pumps, pipes and other equipment with user-defined alarms. Additional Fluke Process Instruments exhibits will include thermal cameras, infrared sensors for continual process and asset monitoring, and handheld Fluke devices for spot-checking.
Fluke Process Instruments at Maintenance NEXT
Rotterdam, 18 – 20 April 2023
Hall 2, Booth 106

Fluke Process Instruments will showcase temperature monitoring solutions for quality control in glass manufacturing, forming and coating processes at the glasstec trade fair in Düsseldorf, Germany (Booth 14-A41). The lineup features various infrared sensors and thermal imaging systems for non-contact temperature measurement and analysis. Real-time feedback and comprehensive connectivity options ensure easy integration in factory control systems. Line operators receive real-time process information to help them increase plant productivity, improve ROI and minimize operating costs. The MP Linescanner series provides live thermal imaging of moving processes such as float glass manufacturing and flat glass tempering, checking for temperature uniformity as well as physical damage and detecting hot spots and cold spots. For monitoring the temperature curve inside the furnace, Datapaq dataloggers are available, which track temperatures via thermocouples attached to the glass sheet surface. The manufacturer furthermore offers a full range of infrared pyrometers with suitable wavelengths for all kinds of applications in the manufacture of bottles, vials, ultra-thin drawn glass for touchscreens and much more.
Fluke Process Instruments at glasstec
Düsseldorf, Germany, 20 – 23 September 2022
Hall 14, Stand A41

Fluke Process Instruments will be a co-exhibitor at Holland Robotics’ automatica booth (#B4.119) in Munich, Germany, showcasing its new SV600 Fixed Acoustic Imager, which enables users to detect, locate and track air or gas leaks before they incur high maintenance and repair costs. The focus will be on agile robotic applications for the acoustic camera: the SV600 has been integrated in Boston Dynamics’ robot dog Spot, which enables monitoring in difficult-to-access or potentially unsafe environments. There will be live demonstrations of the technology at the automatica booth every two hours. Using an array of sophisticated sound sensors, a camera and Fluke’s powerful SoundMap technology, the SV600 visualizes sounds for asset monitoring, troubleshooting and quality inspection. It easily integrates with factory systems and, as a mounted device, enables 24/7 monitoring of compressors, pumps, pipes and other equipment with user-defined alarms. Remote evaluation options help minimize operator intervention, thus improving factory safety.
More information: https://www.flukeprocessinstruments.com/en-us/products/sv600-fixed-acoustic-imager

Fluke Process Instruments at automatica
Munich, Germany, 21 – 24 June 2022
Hall B4, Stand 119 (with Holland Robotics)

At the 2022 Hannover Messe, Fluke Process Instruments (Stand #8-D34) will present its new SV600 Fixed Acoustic Imager, which enables users to detect, locate and track air or gas leaks before they become costly problems. Using an array of sophisticated sound sensors, a camera and Fluke’s powerful SoundMap technology, SV600 visualizes sounds for asset monitoring, troubleshooting and quality inspection. It easily integrates with factory systems and enables 24/7 monitoring of compressors, pumps, pipes and other equipment with user-defined alarms. Remote evaluation options help minimize operator intervention, thus improving factory safety. Notably, the SV600 acoustic imager has already been integrated, as a payload, in Boston Dynamics’ agile robot Spot for autonomous and remote-controlled surveillance in difficult-to-access or potentially unsafe environments.

More information: https://www.flukeprocessinstruments.com/en-us/products/sv600-fixed-acoustic-imager

Fluke Process Instruments at Hannover Messe
Hanover, Germany, 30 May – 2 June 2022
Hall 8, Stand D34

Fluke Process Instruments will present its versatile portfolio at the SENSOR+TEST and SMTconnect trade fairs, which will run in parallel at the Nuremberg Exhibition Center on 10 – 12 May 2022. The SENSOR+TEST booth will showcase the full range of measurement solutions, highlighting the company’s new SV600 Fixed Acoustic Imager, designed to detect and locate air and gas leaks or changes in sound signatures that can point to mechanical faults. Using an array of sophisticated sound sensors, a camera and powerful SoundMap technology, the SV600 visualizes sounds for asset monitoring, troubleshooting and quality inspection. In addition to stationary installations, it is available as a payload for the Boston Dynamics agile robot Spot, which can access parts of a facility that are hard to reach or pose risks for humans.
Fluke Process Instruments will also present its infrared temperature measurement and thermal imaging solutions at SENSOR+TEST, from highly economical sensors to the most sophisticated systems in the market. The company offers various pyrometer series for operation in the most demanding industrial environments, including OEM models with the lowest cost per measuring point, as well as two kinds of thermal imaging solutions: thermal cameras and infrared linescanning systems for continuous processes. They have been successfully deployed in hundreds of different industry applications.
SMTconnect exhibits will focus on industry-specific thermal profiling solutions for electronics manufacturing. Datapaq Reflow Trackers monitor wave and reflow soldering, vapor phase soldering, selective soldering as well as solder work at repair stations. The manufacturer offers an entire family of these temperature profiling systems for all kinds of oven setups, including miniaturized versions. The portfolio comprises various data loggers, thermal barriers, thermocouples and sensor holding frames. The accompanying software visualizes temperature profiles and supports troubleshooting, quality assurance and trend analysis; functions include maximum temperature, maximum slopes, contact time, and line speed. Users do not even have to wait for the profiler to exit the oven to visualize and analyze the data: an integrated radio transmitter optionally provides real-time data from within the process. All process and system data can also be communicated to factory-monitoring systems via the OPC interface.

Fluke Process Instruments booth numbers:
SENSOR+TEST #1-655
SMTconnect #4-145

Fluke will present its versatile portable and fixed acoustic imaging solutions at two UK tradeshows in March and April: Hydrogen Tech Expo at Telford International Centre and Plant & Asset Management at NEC Birmingham.
The SV600 Fixed Acoustic Imager from Fluke Process Instruments enables users to detect, locate, and visualize air and gas leaks or changes in sound signatures across their process and equipment in real-time before they become costly problems. The handheld Fluke ii900 Industrial Acoustic Imager visualizes the sounds coming from small leaks in compressed air, gas, and vacuum systems, as part of routine inspections, and helps customers drive greater energy efficiencies.
Using an array of sophisticated sound sensors, a camera and powerful SoundMap technology, the SV600 and ii900 series visualize sounds for asset monitoring, troubleshooting and quality inspection for manufactured products that are tested for air leaks. The SV600 easily integrates with factory systems and enables 24/7 monitoring of compressors, pumps, pipes and other equipment with user-defined alarms. Remote evaluation options help minimize operator intervention, even in parts of the facility that are hard to reach – notably the SV600 has already been integrated, as a payload, in the Boston Dynamics agile robot Spot for surveillance in difficult-to-access or potentially unsafe environments.
Fluke Process Instruments also provides a comprehensive range of rugged infrared temperature measurement and thermal imaging solutions as well as Datapaq thermal profiling systems and will be happy to advise tradeshow visitors regarding their individual measurement tasks. Various dedicated hardware and software solutions are available for all kinds of industrial applications, including customized implementations.

Fluke Process Instruments, a global leader in infrared imaging and thermal profiling solutions for industrial applications, debuts its latest temperature monitoring system – the CS400 Kiln Shell Imaging System. Specifically designed for harsh kiln environments, the CS400 is a fully integrated solution that continuously monitors rotary kilns for hot spots and can picture every brick in real-time to detect wear and tear, prevent costly damages and unscheduled downtime, and extend production runs and the kiln’s operational life. At the core of the system is the MP Linescanner, which provides accurate, edge-to-edge and real-time thermal imaging and temperature measurement for a complete picture of continuous processes.
The CS400 features specially designed software, which relies on standard Ethernet ports. Because the graphic user interface is designed specifically for kiln applications, the software is easy to set up and use with little operator training required. Once set up, the software provides a thermal image of the entire kiln shell surface, with a zoom function that allows detailed examination for key areas of interest. Temperature range and zone alarms can also be easily configured within the software; and other information – such as burn zone temperature, lap time and the scanner’s internal temperature – is displayed in the status bar for a complete system status without changing screens.
“Continuous infrared monitoring is essential for rapid detection of temperature anomalies, such as non-uniformities and hot spots in a kiln’s refractory material,” says Stewart Griffiths, Global Product Manager, Fluke Process Instruments. “Our new Kiln Shell Imaging System can measure up to 1024 temperature points across a scan line and features specially-developed software. With multiple kiln support, polar charts highlighting coating thickness and brick thickness, and envelope profiles over the entire kiln, manufacturers can easily optimize and manage maintenance schedules to avoid costly shutdowns, as well as reduce setup times with intuitive configurations and temperature profile calculations.”
The CS400 Kiln Shell Imaging System is now available. To start picturing every brick in rotary kilns in real-time and contact a subject matter expert, visit https://get.flukeprocessinstruments.com/cs400/emedia/.

At the productronica trade fair in Munich, Germany, Fluke Process Instruments (booth #A1-325) will present tested and proven temperature profiling systems for quality assurance in electronics manufacturing. The extensive portfolio includes comprehensive hardware and software solutions for both fully automated production lines and for rework and manual inspection. These systems travel along with the PCBs through every stage of the process including the preheating phase, capturing detailed temperature profiles along the way based on data gathered by up to 12 sensors. The Datapaq Reflow Tracker line comprises industry-specific data loggers, thermal barriers, a wide selection of thermocouples and the Datapaq Insight software, which quickly transforms raw data into actionable information and features functions for easy oven setup. The new Datapaq Insight for Mobile app allows users to quickly check thermocouple operation and analyze data on the factory floor, without the need for a PC. The latest generation of data loggers, the Datapaq DP5 series, provides a ±0.5 °C accuracy and a ±0.1 °C resolution. One logger can survey up to 10 ovens in succession, storing individual profiles with up to 600k data points in total. Fluke Process Instruments is continuously adding new Datapaq temperature profiling solutions to its portfolio. Standard and customized products are developed in close exchange with customers to optimally suit practical requirements.
In addition, Fluke Process Instruments will also showcase infrared technology for noncontact temperature measurement. Applications for the ThermoView TV40 thermal imager include, amongst others, the quick detection of faulty solder joints. Another highlighted product line, the versatile Raytek Compact MI3 pyrometer series, is designed especially for easy integration in plants and machines and minimal costs per measurement point. The team will be happy to advise productronica visitors on the best way to tackle their specific measurement and monitoring tasks.
Fluke Process Instruments at the productronica trade fair
Munich, Germany, 16 – 19 November 2021
Hall A1, Stand 325

Fluke Process Instruments, a global leader in infrared imaging and thermal profiling solutions for industrial applications, releases its first fixed acoustic imaging solution. The SV600 Fixed Acoustic Imager enables users to detect, locate and visualize air and gas leaks or changes in sound signatures across their process and equipment in real-time before they become costly problems. By using an array of sophisticated sound sensors and powerful SoundMap technology, the SV600 translates the sounds that it hears into a visual representation so users can quickly locate and quantify problem areas.
The SV600 easily integrates with factory systems and can serve as an early warning system that can quickly detect changes across compressors, pumps, pipes, conveyors or across product inspection and quality control processes, and much more with user-defined alarms. Remote evaluation options, meanwhile, help to minimize operator intervention, even in parts of the facility that are hard to reach.
“With automated acoustic imaging that the SV600 brings, maintenance teams can visualize leaks or sound signature changes to factory equipment or assets, and prevent unscheduled maintenance and possible costly downtime, and at the same time improve factory safety by minimizing operator intervention,” says Herman Warnshuis, president, Fluke Process Instruments. “We are excited to bring this new technology to customers across the globe and cannot wait to see how they utilize the technology to detect, locate and visualize sound signature changes or leaks in their process.”
The SV600 can also be used a payload for Boston Dynamics’ agile mobile robot Spot, which takes inspection to the next level. Designed to go where other robots cannot go and to perform a broad number of tasks, Spot traverses large facilities or unstructured terrain to automate industrial inspections, monitor remote or difficult-to-access environments and provide situational awareness in remote settings. With the SV600 payload, Spot can be reconfigured to automate air and gas leak detection, increase maintenance team efficiency, greatly reduce safety risks and reduce energy costs.
The SV600 Fixed Acoustic Imager is now available.
More information: https://lp.flukeprocessinstruments.com/sv600/fixed-acoustic-imager/pr/

Video clips
https://youtu.be/BXAMvlqdvX4 „SV600 Fixed Acoustic Imager from Fluke Process Instruments“
https://youtu.be/0cu2bT6fdZY „SV600 Fixed Acoustic Imager Payload for Boston Dynamics Spot“

Fluke Process Instruments, a global leader in infrared imaging and thermal profiling solutions for industrial applications, releases the latest Datapaq® Furnace Tracker System – complete with the TP6 data logger, thermal barriers and intuitive software.
The Datapaq Furnace Tracker System is designed to be used repeatedly, in-process in the most hostile manufacturing environments, providing accurate and reliable through-process temperature surveys. Each system can help users improve process performance, decrease downtime, reduce temperature uniformity survey (TUS) reporting times and more.
The first component of the system is the Datapaq® TP6 Data Logger, which can withstand the longest, most-demanding operating conditions. The Datapaq TP6 features a 316-grade, stainless-steel case and a IP67 rating, making it water-resistant. This datalogger is available with either 10 or 20 thermocouple inputs and can be specified for use with base or noble metal thermocouples.
The latest thermal barrier models are ideal for high-temperature heat treat processes and have been designed to provide maximum thermal protection – including applications such as vacuum and controlled atmosphere, slab reheat and solution aging, among others. The new patented quenchable thermal barriers eliminate the need for fiber blankets. Fluke Process Instruments also offers bespoke design services to create a solution that specifically fits a customer’s process.
To complete the system, Fluke Process Instruments offers the Datapaq Insight™ Software, which transforms raw data into actionable analytics and features a clear user interface, context-sensitive help screens and assistance options for infrequent users. Three software options are available, and the complimentary Datapaq Insight for mobile is offered for free. This mobile application allows users to reset, download and analyze right on the factory floor and check thermocouple operation before a thermal profile run. The advanced TUS software also provides full temperature profiles and traceable reports for industry regulations like AMS2750 and CQI-9.
“The latest Datapaq Furnace Tracker System offers customers a robust solution that is designed for harsh environments like quenching and high temperatures,” says Rob Hornsblow, Product Manager at Fluke Process Instruments. “Whether users are working with raw materials or finished products, measuring product and atmosphere temperatures throughout the furnace is critical in ensuring both product quality and process efficiency. Datapaq continues to provide real-time, repeatable temperature data that can help improve performance and system accuracy, decrease downtime and much more.”
“We’ve really focused on what customers wanted when engineering this new system, and we are excited to introduce the patented quenchable thermal barriers, an IP67-rated data logger and the Insight for Mobile application that will allow users to check thermocouple operation before each run.”
The Datapaq Furnace Tracker Systems – including the new TP6 Data Logger and thermal barrier models – are now available. To learn more, or to speak with a specialist in your region, visit https://lp.flukeprocessinstruments.com/datapaq-thermal-profiling-solutions/pr/.

Fluke Process Instruments expands its Thermalert 4.0 pyrometer series, adding intrinsically safe models and HART protocol as an additional interface option. The rugged, intelligent and compact infrared temperature sensors in an IP65-rated stainless-steel housing are easy to connect via 2-wire installation. The series provides a future-proof, Industry-4.0-ready solution for non-contact, automatic, real-time temperature monitoring. Various spectral models cover a large measured temperature range from -40 °C to 2300 °C and all kinds of industrial applications, such as primary and secondary metals, glass and plastics manufacturing. The new intrinsically safe models rated Ex ib now add infrared thermometer options for use in hazardous environments with potentially explosive gas or dust atmospheres (zones 1 and 21). Accordingly, all models are optionally available with an ATEX/IECEx/CCC-IS certification, with the only exception of sensors with plastic lenses. The IR temperature sensors feature galvanically isolated analog and RS485 interfaces. Up to 32 devices can be connected within an RS485 network. All models are also available with connectivity options for Ethernet, EtherNet/IP, PROFINET IO and HART protocol as the latest addition. Voltage can be supplied via Power over Ethernet (PoE). A large choice of optics is available for long and short focal distances. The IR sensors achieve outstanding optical resolutions and provide high-precision data for efficient process control and quality assurance. The Thermalert 4.0 series features an exceptionally high maximum operating temperature of 85 °C, which allows users to save costs by setting up many measuring points without cooling. Moreover, the sensors can be read out, configured, calibrated and fitted with firmware updates remotely via the internet. This minimizes service costs per measuring point. An integrated laser focus facilitates alignment. The easy installation additionally facilitates commissioning and maintenance.

Fluke® Process Instruments, a global leader in infrared temperature measurement and thermal profiling solutions for industrial applications, introduces the MP Linescanner Series, which delivers continuous, accurate, edge-to-edge thermal images and temperature measurements for high-speed manufacturing processes. The series features Fluke’s widest selection of spectral and temperature ranges to accommodate a variety of industrial applications. The new imagers provide real-time imaging at scan speeds up to 150 or even 300 Hz: three shortwave models deliver maximum scan rates of 300 lines per second; these are geared primarily at the metals industry.

“Scan rate is essential for rapid detection of temperature anomalies, such as non-uniformities and hotspots,” said Dr. Martin Budweg, Global Product Manager, Fluke Product Instruments. “The new MP Linescanners can measure up to 1024 temperature points across a scan line at a rate of up to 300 lines per second, allowing manufacturers to better control their continuous moving processes, automate temperature measurements, and ensure product quality.”

The versatile MP Linescanner Series features rotating optics and a 90-degree field of view that quickly renders a 2D image on a PC. Additional key features include:

– High-quality brushless motor (MTBF 40,000 h)
– Built-in Ethernet TCP/IP communications
– PC-independent alarm output
– PC-independent 4 – 20 mA interfaces (3 outputs)
– I/O module support for up to 10 sectors/zones (PC-independent)
– Internal line laser for accurate alignment
– Rugged, waterproof IP65 enclosure
– Air purge to keep the window free of dirt and condensation
– Built-in water cooling for ambient up to 180 °C (356 °F)

DataTemp DP Software provides real-time monitoring and remote configurations

The MP Linescanner Series can be used in standalone mode, connected to a single PC, or integrated into a comprehensive process control system by using the DataTemp® DP Software. This industrial Windows-based software package provides remote configurations of the imager and real-time process monitoring. The DataTemp DP Software supports multiple product-specific configurations (recipes), text file alarm logging, and fail-safe alarm logging. It features the ability to support multiple linescanners and real-time ambient temperature compensation/emissivity adjustments.

Fluke Process Instruments offers numerous customized process imaging systems to meet the specific application requirements for processes like glass processing, extrusion coating, thermoforming machine control, kiln shell monitoring, and gypsum wallboard production. Each customized system features application-specific software to help ensure product quality, quality improvements, reduced rework rates and more.

More information: https://lp.flukeprocessinstruments.com/mp300/ien/

For all industry applications that need real-time, accurate, detailed temperature data, Fluke Process Instruments provides rugged, high-performance noncontact infrared sensors and solutions. The comprehensive portfolio includes single spot pyrometers and two kinds of thermal imaging systems: linescanners and thermal cameras. Installed at a safe distance, these systems enable continuous temperature monitoring and control from -40 °C to 3200 °C. Each product range offers suitable wavelength models for various applications that can measure repeatably even under arduous conditions. Output options include analog signals, industrial protocols, OPC, and web server. Devices with analog and digital output types can be run simultaneously, for example, Profinet and video streaming. Various software packages capture, log, and visualize temperature data and allow users to configure hardware or software alarms. Spot pyrometers are designed for pinpoint measurement of small target areas. Ratio pyrometers can even measure objects that are smaller than the field of view, such as thin wires or molten streams of glass or metals. Unique sighting options – including remote video viewing with the Endurance sensor – enable users to ensure the measurement is always on target. Multiple-head, single-interface options plus networking of multiple devices can reduce installation costs. OEM miniature versions offer easy integration without the need for additional interfaces and are supplied with full protocol information and an optional hardware developer kit. Thermal imaging systems can provide a full perspective on processes, equipment, and the surrounding environment. The Linescanner series enables real-time thermal imaging for continuous or batch processes, scanning moving objects line by line to create thermograms and temperature profiles. The ThermoView TV40 thermal camera is used to monitor continuous and discrete processes as well as equipment and facilities. Users can define multiple discrete temperature measurement areas (AOI) for temperature uniformity checks, hot and cold spot detection, and trend analysis. The complementary Pan and Tilt enclosure for the TV40 enables 360° monitoring at multiple heights. Single views can be combined in software to create a large matrix view. A comprehensive range of accessories is available to protect the devices from heat and cold and reduce contamination, ensuring reliable performance between planned maintenance. Each of these technologies has its strengths. For some applications or problems, a combination of different devices may be the best solution. The international technical and application support team advises customers on the optimal system configuration for their project.
More information: https://lp.flukeprocessinstruments.com/infrared-temperature-solutions/directindustry/eblast/

Fluke Process Instruments offers powerful sensing tools for glass vial and syringe production that allow manufacturers to ramp up production while ensuring consistent high product quality. Processes need to be optimized for high throughput and productivity now that the COVID-19 vaccination drive increases the demand for medical glass products. Fluke Process Instruments supports the medical glass industry in establishing application-specific temperature monitoring solutions that provide the comprehensive, accurate, and traceable data needed. The company manufactures data loggers and non-contact infrared sensors and advises customers on the correct choice and configuration for processes such as gob forming, glass pre-heating, shrinking, flanging, forming, cutting, annealing stress testing, and more. Fluke Process Instruments is a leading international manufacturer of industrial temperature measurement systems. Spot pyrometers are a non-contact solution used to monitor temperatures both in moving lines and stationary processes. There are specialized wavelength models for measuring glass, and the Marathon MM, Endurance, and Thermalert 4.0 series provide options for very cost-sensitive applications as well as for the most advanced requirements. In addition, the ThermoView TV40 thermal imager is available for continuous monitoring of forming and sealing processes. Complementing the infrared pyrometry portfolio, the Datapaq Furnace Tracker line features high-temperature through-process profiling technology based on a data logger and thermal barrier. These systems measure the temperature of the products as they pass through the furnace via short thermocouples attached to the glass. The accompanying software facilitates process control, optimization, and validation.
More information: https://get.flukeprocessinstruments.com/glassvials/directindustry/eblast/

Fluke Process Instruments offers powerful sensing tools for glass vial and syringe production that allow manufacturers to ramp up production while ensuring consistent high product quality. Processes need to be optimized for high throughput and productivity now that the COVID-19 vaccination drive increases the demand for medical glass products. Fluke Process Instruments supports the medical glass industry in establishing application-specific temperature monitoring solutions that provide the comprehensive, accurate, and traceable data needed. The company manufactures data loggers and non-contact infrared sensors and advises customers on the correct choice and configuration for processes such as gob forming, glass pre-heating, shrinking, flanging, forming, cutting, annealing stress testing, and more. Fluke Process Instruments is a leading international manufacturer of industrial temperature measurement systems. Spot pyrometers are a non-contact solution used to monitor temperatures both in moving lines and stationary processes. There are specialized wavelength models for measuring glass, and the Marathon MM, Endurance, and Thermalert 4.0 series provide options for very cost-sensitive applications as well as for the most advanced requirements. In addition, the ThermoView TV40 thermal imager is available for continuous monitoring of forming and sealing processes. Complementing the infrared pyrometry portfolio, the Datapaq Furnace Tracker line features high-temperature through-process profiling technology based on a data logger and thermal barrier. These systems measure the temperature of the products as they pass through the furnace via short thermocouples attached to the glass. The accompanying software facilitates process control, optimization, and validation.
More information: https://get.flukeprocessinstruments.com/glassvials/directindustry/eblast/

Fluke Process Instruments will exhibit temperature sensing solutions at the European Conference on Heat Treatment in Antwerp, Belgium. The manufacturer develops both infrared sensors for continuous remote monitoring of equipment and processes and datalogging systems for furnace surveys and in-process product temperature profiling. Designed to meet today’s demanding industrial automation requirements, the hardware and software systems allow operators to optimize their processes for consistent high quality and fuel efficiency. An exhibition highlight, the ThermoView TV40 industrial-grade thermal imager with an integrated visible-light camera, enables 24/7 temperature monitoring in a -10 °C to 1200 °C range. Target applications include iron foundries where the imagers check temperatures of molten metal and monitor ladles to ensure that the refractory lining is intact. Users can define various areas of interest with distinct alarm conditions. Also on show, the Datapaq Furnace Tracker performs temperature uniformity surveys (TUS) and system accuracy tests (SAT) compliant with NADCAP AMS 2750E and CQI-9. This system is based on the Datapaq TP3 data logger with up to 20 measurement channels. It is designed to travel through heat-treatment and quench processes. Datapaq thermal profilers include analysis and reporting software, thermocouples, and thermal barriers. The team will be happy to advise visitors on the best way to tackle their particular measurement needs.
ECHT European Conference on Heat Treatment
Antwerp, Belgium, 25 – 27 March 2020
