Launching PROFITEST H+E EXPERT CHECK, Gossen Metrawatt introduces a robust diagnostic tester corresponding to measurement category CAT III 300 V for standard-compliant functional testing of AC charging stations in accordance with DIN EN/IEC 61851-1 (VDE 0122-1). The handheld tester enables electricians to quickly and reliably test the functionality, electrical safety and personal protection of 1- and 3-phase AC charging points in charging mode 3 on a type 2 socket or a permanently connected type 2 cable. As a unique selling proposition in this product class, the device provides standard-compliant testing of PE interruptions with graphical display of measured values. The functional range includes the verification of vehicle states A, B, C and D; phase tests and phase sequence tests; diode testing; evaluation of the PWM signal for data communication and abortion of the charging process during short-circuit simulation as well as determination of battery charging levels. In combination with installation testers from the PROFITEST MF or PROFITEST MASTER IQ series, the device can also be used as a test adapter for electrical testing of the charging infrastructure thanks to its measuring inputs and earthing contact socket. In addition to the charging function tests, all relevant safety tests can also be carried out in this combination, including, for example, low-impedance continuity of the conductors, insulation resistance, tripping of the residual current circuit breaker (RCD/FI), 6-mA sensors and loop and internal mains resistance. Measured values and test results are shown in plain text on the device display.

The measurement and testing technology specialist Gossen Metrawatt expands its cost-effective, user-friendly METRALINE series, adding a new multifunctional installation tester. METRALINE MF, certified for CAT III 600 V / CAT IV 300 V, enables all required tests in electrical systems and installations in accordance with the current DIN VDE 0100-600 and DIN VDE 0105-100 standards. The portable, battery-powered tester features a graphic color display and easy menu navigation for intuitive operation and convenient operation. Support functions such as help images and audio signals help to carry out the measurement tasks. The comprehensive test spectrum includes low-resistance measurement with 200 mA and automatic polarity reversal, loop and mains impedance measurement with RCD, 3- and 4-pole earthing measurements, insulation measurements up to 1000 V and RMS voltage measurement. In addition, all measurements of commercially available RCDs and RDC-DDs with 6 mA DC for electric charging points can be performed. Up to 1000 measurement data can be stored in the large instrument memory and made available in just a few steps with the integrated METRAreport software for generating test reports. Regular firmware updates keep the installation tester up to date. Gossen Metrawatt supplies the new METRALINE MF complete with carrying case, power supply unit and rechargeable batteries. The extensive range of accessories includes three 1-m measurement cables, three test probes and alligator clips each, as well as one measurement cable, each with earthing contact plug or test button.

Gossen Metrawatt presents a newly developed web-based platform solution for comprehensive, transparent energy data management: METRAVIEW is a universally implementable software platform for acquisition, storage, visualization and analysis of energy and process data. It provides reliable access to consumption data and key figures independent of location and device, supporting companies in the implementation of software-based energy management according to ISO 50001. METRAVIEW functions include checking the efficiency of measures in the PDCA cycle and the plausibility of data and measurement concepts, furthermore forecasts, energy data and cost acquisition, cross-media consumption determination and cost center attribution. User-specific dashboards, high-quality process images and powerful trend analyses ensure simple, intuitive energy and process data evaluation. Graphical elements such as speedometers, bar graphs, totals or diagrams can be individually selected and organized in an easy manner. METRAVIEW’s SCADA functionality ensures high-performance updating of all data, high refresh rates and high-quality system visualization in user-specific designs. Based on definable limit values, an integrated alarm platform triggers automatic warnings by email, phone or SMS in the event of a fault or greatly increased energy consumption. Thanks to long-term archiving of all operating and fault messages, historical events can be fully traced. Open standard interfaces based on OPC technology enable manufacturer-independent communication. Standard and application-specific protocols such as Modbus, IEC 60870-5-104 or Profinet can be easily implemented to connect existing and third-party hardware devices from a wide range of manufacturers. The user-friendly reporting tool allows for data to be converted into graphically enhanced reports and documentation. TLS-encrypted access, two-factor authentication, configurable user management with access rights at different levels, user-definable password requirements and adjustable log-in restrictions contribute to a high level of IT security.

Gossen Metrawatt expands its range of MID-certified active energy meters, introducing the new, especially compact and cost-effective METRALINE ENERGY series. The devices approved for billing purposes feature accuracy class B for measuring active energy according to EN 50470-3. Active and reactive power of energy import and export are recorded by means of 4-quadrant measurement. This makes the new meter generation ideal for use in industry, commerce and building technology. At widths of only 18 mm, 36 mm and 72 mm, the meters allow for top-hat rail mounting in installations with very high packing density. 12 models with three different interfaces are available. They are designed for 2- and 4-wire AC systems with direct or transformer connection. The most compact units, only one modular spacing wide, offer a choice of three single-phase active energy meters for 2-wire systems, in the 230 V voltage range with direct connection up to 40 A. Next in line, there are three 36 mm wide single-phase meters for 230 V direct connection up to 80 A. The new series is completed by three 3-phase models for measurement in 4-wire systems up to 400 V with direct connection or 1 A/5 A current transformer connection. All four device classes are available with 2xS0 pulse outputs or Modbus RTU or M-Bus data communication interfaces. The cover can be sealed to protect against tampering.

Since the end of the transition period in September 2023, periodic testing of electrical equipment must comply with DIN EN 50699 requirements. Gossen Metrawatt has a future-proof solution on hand and offers the latest generation of its SECUTEST ST device tester series at particularly attractive conditions. The safety testers with a distinctive lemon green housing design integrate all currently required test sequences according to DGUV Regulation 3 and MPBetreibV (German Medical Device Directive). They simplify professional, standard-compliant periodic testing for electrical safety per DIN EN 50699. This makes the series ideal for use in industry, trade and public institutions, for example. The measuring range includes the testing of protective conductor and insulation resistance, various leakage currents as well as SELV and PELV (safety/protective extra-low voltages). In addition, the devices can be used to check the time to trip for portable residual current devices (PRCD), functional tests of U, I, P, S, LF, f and cable tests for continuity, short circuiting and polarity. Automatic and individual test sequences ensure an effective and safe implementation of the standards. A practical rotary switch, direct selection keys and soft keys enable intuitive and reliable access to all test functions. Gossen Metrawatt supplies the tester in a bundle with an EL1 adapter, barcode reader and including a Business Professional license for the IZYTRONIQ software for networked, cross-device test data management.

As of July 2023, Kurth Electronic GmbH, which has been part of the GMC-Instruments Group since 2016, will be incorporated into Gossen Metrawatt GmbH while the Kurth Electronic brand will continue. Gossen, a leading manufacturer of test and measurement technology for electrical safety, thus expands its portfolio in telecommunications and data technology. “We are confident that the integration will combine the strengths of both companies and enhance our capability to offer our customers state-of-the-art, innovative measurement and testing technology for their requirements today and in future,” says Marcel Hutka, Managing Director at Gossen Metrawatt. In addition to the Gossen Metrawatt and Kurth Electronic brands, the Group’s portfolio also comprises Camille Bauer measurement solutions for network analysis and power quality and the Rigel Medical brand with measuring and test equipment for medical technology.

Gossen Metrawatt has introduced the new battery-operated PROFITEST H+E EASY CHECK for simple, safe testing of AC charging points at the touch of a button. No electric training is necessary to safely check infrastructures for single- and three-phase charging processes using this device, which corresponds to the CAT III 300V measurement category and is designed for 20A and 32A cables. Charging station operators, service providers and non-professionals can use the automatic device for function testing according to DIN EN/IEC 61851-1 (VDE 0122-1) in charging mode 3 at type-2 sockets or with a permanently installed type-2 cable. The functional range includes the verification of vehicle states A, B and C; phase tests and phase sequence tests; evaluation of the PWM signal for data communication and abortion of the charging process during short-circuit simulation; and determination of battery charge levels. Test results are shown in plain text on the device display and any detected malfunctions are saved as error messages. This way, if a charging process does not work properly, users can run quick and cost-efficient checks on the charging point or wallbox and need only call a qualified electrician if they detect functional errors. In addition to standards-compliant testing, the device is also suitable for complete professional functional testing of AC charging stations, thus eliminating the need for additional devices such as multimeters or oscillographs. Gossen Metrawatt supplies the PROFITEST H+E EASY CHECK complete with operating instructions and micro-USB charging cable.

GOSSEN METRAWATT has launched the new PROFITEST MF series of installation testers that meet all requirements for professional, standards-compliant electrical testing of installations and systems. Building on the established PROFITEST series, the new MF generation boasts multifunctionality, intuitive operation and excellent usability due to easy selection of measuring and control functions via a rotary switch, automatic test sequences and a high-resolution, context-sensitive color graphic display. In addition to stored test procedures compliant with common standards such as IEC 60364-6 (DIN VDE 0100-600) and EN 50110-1 (DIN VDE 0105-100), individual test sequences can be programmed. Further current test routines are available on the myGMC download portal, for example, functional testing of the charging infrastructure for electric vehicles. PROFITEST MF testers feature redesigned help functions to facilitate correct testing including detailed circuit diagrams, lists of measuring functions and much more. The new series is a future-proof measurement and testing solution offering a variety of applications and an extensive range of accessories including adapters. GOSSEN METRAWATT’s 10-year service guarantee ensures the devices will continue to be up to date permanently. Additional measurement functions can be easily installed as firmware updates via USB. Due to their high connectivity, PROFITEST MF testers can be easily integrated into the cross-device, integral measurement data management system IZYTRONIQ. The new installation testers are supplied with extensive accessories, DAkkS calibration certificate and documentation. They are among GOSSEN METRAWATT’s first products featuring the newly designed sustainable packaging.

Launching the METRAHIT IM TECH BT, Gossen Metrawatt completes its new generation of digital TRMS multimeters. METRAHIT IM series mains-independent universal multimeters come with a patented quick-change rechargeable battery and are the only handheld devices on the market to integrate a four-wire milliohm measuring function with up to 1 µ? resolution. The new IM TECH BT model, which is tailored to use in industrial production and testing areas and service in the field, covers a wide range of tests. Thus, this economical solution is ideal for maintenance, service and diagnostics on electric machines and drives as well as systems from the automotive, energy and automation sectors. Milliohm measurement with an adjustable measuring current of 200 mA or 1 A makes it possible to precisely determine even minimal contact resistances in welded and rivet connections, e.g., on aircraft outer skins (Wick test) and precisely measure the equipotential bonding of hybrid and electric vehicles according to UN ECE R100 with 200 mA. The DAkkS-calibrated multimeter conforms to measurement category 1000 V CAT III. Its functional scope also includes TRMS measurements for current and voltage up to 10 kHz or 100 kHz and precision temperature measurements with RTD resistance sensors and type K thermocouples. Additional functions include capacitance measurement, direct and indirect current measurement with clamp sensors, diode testing under constant current and quick continuity testing for short circuits and interruptions with acoustic signaling. Users can activate a 1-kHz low-pass filter to detect dangerous voltages, e.g., on cables with parasitic external signals. The various measuring functions can be selected easily and safely via a rotary switch. Test sequences, measurement settings and results are clearly displayed on a 3.5“ TFT color display with good legibility even in bright light. The integrated datalogger with a real-time clock saves up to 300,000 measured values, which can also be directly transmitted to the test software using the push/print function. A Bluetooth interface is integrated for data communication. The METRAHIT IM TECH BT, which provides protection against dust and splashing water according to IP52, is supplied with a protective rubber cover, hard case, lithium-ion battery, USB charger, safety measuring cables, Kelvin clips, DAkkS calibration certificate, short-form operating instructions and with an IZYTRONIQ Business starter license.

Introducing the MAVOWATT 210, Gossen Metrawatt completes its range of portable energy and power quality meters, adding an economical and – at only 640 g – very light device. The bidirectional datalogger precisely measures all parameters relevant for ensuring the quality of the energy supply both on the power utility and consumer side. Reductions in power quality such as voltage drops, dips or interruptions and overvoltages are detected with a resolution of 1/2 cycles according to IEC 61000-4-30, and harmonics are recorded according to IEEE 519-2014/IEC 61000-4-7. The device, which has four voltage channels for direct measurement up to 600 VRMS (CAT III) and four current channels, is suitable for all relevant performance parameters such as voltage, current, active, reactive and apparent power. In addition, it serves as a high-precision bidirectional four-quadrant measuring device for energy flow detection, e.g., in wind power and photovoltaic systems. Automatic detection of the type of connection and indication of connection errors via color-coded LEDs ensure safe operation at all times. The compact MAVOWATT 210 allows for up to seven hours battery-powered operation in any local or remote system. For visualization and evaluation, an integrated Ethernet interface with a web server enables real-time access to all present and previously logged measured values. Operators can create analyses and reports using the Dran-View XP PC software, which is specially adapted to the MAVOWATT 210 and included in the scope of delivery free of charge. Standard equipment furthermore includes three Rogowski coils with a measuring range up to 500 A, four voltage cables and a power supply unit. The manufacturer also offers additional current sensors.

The demand for DC fast charging stations will continue to increase as the transition towards electromobility progresses. Since DC charging stations installed in public or commercially accessible areas are designated for the use by the general public, they must be tested for substantiation of electrical safety in accordance with DIN EN 61851-1 (VDE 0122-1), charging mode 4. Gossen Metrawatt has expanded its portfolio for mandatory functional testing, adding two new diagnostics testers (PROFITEST H+E XTRA and H+E XTRA C), which cover the two common system standards CCS (Combo 2) and CHAdeMO. After the testers have been connected to a charging station and after registration and selection of the test sequences, they perform simulated charging processes from a DC source and load to determine the charging current, charging time and voltage. In addition to measurements for insulation fault detection, DC voltage and direct current, the devices check data communication conformity with ISO 15118-1 or DIN SPEC 70121 for CCS stations or the respective relevant CHAdeMO protocol. A graphic color display with touch input ensures good readability and intuitive operation. In addition, the devices feature 4-mm safety sockets for DC+, DC- and PE for connecting a PROFITEST PRIME installation tester so all necessary measurements can be made under loading conditions to check the effectiveness of protective measures. Measuring tasks covered include checking the low-impedance continuity of the protective conductor; measuring the loop resistance between DC+ and DC-; insulation monitoring in the CCS system; measurements of insulation resistance, residual voltage and contact current; and function control of the residual current protective device.

The latest generation of SECUTEST ST test instruments from Gossen Metrawatt is preset for the requirements of the DIN EN 50678 and DIN EN 50699 standards, which have recently come into effect. The new standards replace the DIN VDE 0701-0702, which is still valid on a transitional basis until 2022/2023. They now introduce distinct regulations for checking the protective measures for electrical safety after repair and during periodic tests. In addition, requirements for individual inspection tasks have changed. For example, a new calculation basis applies to cables over 1.5 mm˛ and leakage current measurement at insulated inputs is now stipulated per standard. Gossen Metrawatt has updated the range of functions of its SECUTEST ST series accordingly and expanded the scope of measurements with new standards-compliant test sequences. The manufacturer offers these new features for download to update earlier device generations. The SECUTEST series is optimized for testing the effectiveness of protective measures for portable electrical, medical and welding equipment. The compact testers measure protective conductor resistances with 200 mA and 10 A, insulation resistances, various leakage currents, as well as safety extra-low voltages (SELV) and protective extra-low voltages (PELV). The scope furthermore includes measuring the time to trip of type PRCD, SPE-PRCD, PRCD-S and PRCD-K RCCBs, function tests with determination of U, I, P, S, LF, f, as well as conductor tests for continuity, short circuits and polarity. The devices also feature a temperature input for a Pt100/Pt1000 sensor as well as a USB port for fast data export, remote control or connecting a report or barcode printer. Two additional USB ports are provided for connecting data entry devices such as barcode readers, RFID readers and keyboards, a USB memory stick for data export in XML format or saving test reports in HTML format. The test device is also available with an optional Bluetooth interface for wireless communication. The safety tester can be used with the IZYTRON.IQ test data management software, for which Gossen Metrawatt offers virtual tutorials with useful practical tips for daily testing tasks at regular intervals until the beginning of June 2022.

Gossen Metrawatt has introduced a new patented solution for secure power supply of its DAkkS-calibrated digital multimeters METRAHIT IM XTRA and METRAHIT IM E-DRIVE. The portable all-in-one devices integrate an exceptionally wide range of testing and measuring functions for maintenance, service and diagnosis of electrical machines, drives and systems. In addition, they also cover measuring methods for safety testing in the automotive industry, avionics and electrical engineering. Gossen Metrawatt has now patented its innovation of a contact-protected connection of the quickly exchangeable supply modules for mains or battery operation. The terminal is recessed into the housing body, effectively ensuring device safety according to CAT III or CAT IV at all times even when exchanging modules or batteries during operation. This solution ensures protection against electric shock according to measuring category 1,000V CAT III, even at overvoltages up to 6,000V. Users can also safely exchange the supply module when the measurement cables are plugged in and the measuring signal is applied, and that without having to disconnect the measurement cables from the test object. Spring-loaded contacts and an extended-length connector format ensure reliable contacting inside the housing. The new patented solution, which is registered by the European Patent Office under publication number EP3474023A2, underlines Gossen Metrawatt’s high innovative capacity in the field of measurement and test technology for electrical safety.

LABKON P series computer controllable KONSTANTERs provide users with DC power supplies for manual and remote control and for laboratory and system use. Their manufacturer GOSSEN METRAWATT now extends the existing product portfolio by two new models for supply voltages up to 20 V. The power supplies with nominal ratings of 500 W and 800 W generate maximum currents of 25 A and 40 A respectively. “Given the large number of applications for 12 V onboard power supplies and the need for higher currents in this voltage range, we have expanded our KONSTANTER portfolio, adding two new LABKON P models,” says Andreas Stollberg, product manager at GOSSEN METRAWATT. All LABKON P devices have good dynamic characteristics with regard to setpoint changes and sudden load changes. The specified nominal values can be delivered continuously thanks to the power output’s outstanding stability, and they can be duplicated at any time with accurate, digital setpoint specification, which assures reproducible results. Users can store individual device configurations to setup memory and retrieve them as required. This saves time when setting up an instrument for recurrent testing tasks. In addition to the standard RS232 port, USB and GPIB (IEEE-488) interfaces are optionally available. The SCPI command set allows for trouble-free integration into automated test systems. The LABKON P series comprises KONSTANTERs with nominal power ratings of 500 W and 800 W. These power supplies provide output voltages between 20 V and 120 V and currents up to 40 A, and thereby cover a wide range of applications.

Nuremberg-based GMC-I Messtechnik GmbH will do business under the name of its own “Gossen Metrawatt” brand as of the 1st of October, 2020. The new Gossen Metrawatt GmbH will thus consolidate the strong reputation of its brand name amongst its customers. “Our customers have known us for decades as Gossen Metrawatt. It only makes sense to include such a strong brand name in the company name as well,” explains Marcel Hutka, Managing Director Technology & Sales. The globally leading specialist in the field of measuring technology has been offering top quality products and solutions made in Germany for more than 114 years. The company’s scope of products and services ranges from measuring and test technology, e-mobility, battery testing technology, medical engineering, energy management, power quality and laboratory power supplies, right on up to digital services for customers. Digitalization is one of the future issues which is being assigned especially high priority at Gossen Metrawatt. “Our intelligent cloud solutions are just one of the many examples of our innovative force in this area,” adds Hutka. “Our innovative effort is focused primarily on electrical safety, as well as reliable and efficient energy supply. Our ultimate goal, both now and in the future, is to provide our customers with expert support for their requirements and to sustainably satisfy them with reliable, future-proof products and solutions with focus on customer.” Company Background As one of the world’s leading suppliers of metrological systems, GMC-I Messtechnik develops and markets a comprehensive spectrum of high quality measuring and test technology for the electrical trades, industry and the field of medical technology under its brand name GOSSEN METRAWATT. The product portfolio includes measuring and test instruments for standards-compliant testing of electrical systems and devices, multimeters, calibrators, power analyzers and power supplies, as well as measuring transducers and power meters for heavy current and rotation angle measurement. Beyond this, the company supports its customers with extensive training offerings and develops concepts for energy management. The group of companies maintains its own calibration department as well as several DakkS accredited calibration centers which perform DakkS, ISO and factory calibration for nearly all electrical and optical measured quantities. GMC-I Messtechnik is a member of the GMC Instruments Group, which also comprises other specialized manufacturers of measuring and test technology including Camille Bauer Metrawatt, Dranetz, Prosys, Seaward, Daytronic and Electrotek Concepts, as well as Kurth Electronic. The group has production locations in Germany, Switzerland, England and the USA, and maintains a global sales network.

Gossen Metrawatt has expanded its newly developed, DAkkS-calibrated multimeter generation, adding a device for the automotive sector. The new METRAHIT IM E DRIVE is an all-in-one solution combining all relevant test and measurement functions for maintenance, service, and diagnostics of electric machines, drives, and systems. Over and above typical multimeter functions, the compact, robust handheld unit integrates various additional measurement methods for safety tests in the automotive industry, avionics, and electrical engineering. The extended functional spectrum includes 4-wire milliohm measurements for precise detection of minimal resistances with resolutions up to 1 µO, high-voltage system tests according to UN ECE R100, and insulation resistance measurements with up to 1000 V according to EN 61557-2/VDE 0413- 2. The multimeter also enables 2-wire Rlow measurements with 200 mA test current according to EN 61557-4/VDE 0413-4. Using the optional coil adapter, users can test electric machines for interturn short-circuits by running a 1000 V impulse voltage test. 4-wire milliohm measurement enables bonding tests by means of equipotential bonding measurement in order to check the discharge capability of the outer skin of aircrafts, for example. METRAHIT IM E DRIVE meets the requirements of the measuring categories CAT III (1000 V) and CAT IV (600 V). Test sequences, measured values, and help texts are clearly displayed on the device’s 3.5″ TFT color graphics display. The multimeter allows users to program their own test sequences. It stores up to 300,000 measured values with time stamps. Current results can be wirelessly transmitted to the accompanying IZYTRONIQ Business Starter test software with the push of a button. The multimeter features Bluetooth and Wi-Fi interfaces. The optional power supply module includes a USB port. In mobile mode, the device runs on a quick-change lithium-ion battery, which can be recharged via micro USB.

Gossen Metrawatt extends the unique functional spectrum of its latest multimeter generation METRAHIT IM XTRA, introducing an adapter for interturn short-circuit tests. Combined with the new COIL ADAPTER XTRA, the robust handheld digital multimeters cover all safety checks for troubleshooting and diagnostics of electric machines, motors, and generators. In addition to insulation defects between winding and housing, users can now also detect interturn short-circuits within a winding of an electric motor with this portable device for field use. In a surge test with 1 kV impulse voltage, the METRAHIT IM and the connected coil adapter reliably recognize even those defects that occur only when operating voltage is applied. The coil adapter is designed for windings with inductances from 10 µH to 5 H. This corresponds to rated outputs of about 160 VA to 80 MVA for 3-phase machines with 400 V rated voltage. After connection to terminals U, V, and W, the semi-automatic test sequence is triggered by a rotary switch. Polarity reversal can also compensate for remanence effects in the rotor. The new coil adapter is available as an optional accessory for the METRAHIT IM XTRA multimeter and the automotive version IM E DRIVE. These are the only available portable universal multimeters that also enable 4-wire milliohm measurements for precise detection of minimal resistances with resolutions up to 1 µO. Their functional range includes insulation resistance tests with up to 1000 V, 2-wire Rlow measurements with 200 mA test current according to EN 61557-4/VDE 0413-4, TRMS current and voltage measurements up to 10 or 100 kHz, high-precision temperature measurements with RTD and TC-K sensors, capacitance measurements, and measurements of the polarization and absorption index. To ensure protection from high short-circuit currents in electric vehicles, the battery-powered multimeters meet the demands of measurement categories CAT III (1000 V) and CAT IV (600 V). The devices are designed for convenient one-hand operation. Their 3.5″ TFT color graphic display ensures excellent readability.

Introducing a portable battery tester, Gossen Metrawatt expands its lineup of measuring and test devices, which help professionals ensure the safe configuration and functioning of electrical equipment. The brand-new METRACELL BT Pro is a versatile solution for testing battery storage systems in DC voltage infrastructures. Above and beyond the required capacity tests, this battery tester can also perform demanding maintenance tasks – it detects premature aging of batteries and thus assures that projected energy output levels are met. For this purpose, the tester measures the electrical and electrochemical resistance, which increase with battery use and aging. A temperature sensor can be connected to the device. Additional METRACELL BT Pro functions include interval measurement with simultaneous logging of the battery block’s or battery system’s voltage up to 600 V and of the charging/discharge current. An integrated RFID transponder system facilitates efficient management of all necessary measurement tasks for hundreds of energy storage facilities and helps eliminate sources of error. The METRACELL BT Pro tester features an interface for Anton Paar DMA35 density sensors to allow maintenance personnel to determine the essential density and temperature values for closed batteries.

Gossen Metrawatt has further expanded its METRALINE product series. Adding the METRALINE PAT, the measurement technology specialist has launched an economical, intuitive device for testing portable equipment in accordance with DGUV Regulation 3. (DGUV is the umbrella association of German statutory occupational accident institutions.) Weighing only 1.3 kg, the compact device tester enables a wide range of protection tests and individual measurements, which can be accessed via shortcut buttons. The tester covers all necessary measurements for repaired or modified electrical devices as well as repeat tests according to DIN VDE 0701-0702. This includes safe and fast testing and measurement of protective conductor resistance, insulation resistance, PE current, touch current, and voltage in SELV circuits. The tester features automatic rating according to normative limits for measuring protective conductor resistance, insulation resistance, leakage currents, and voltages in ELV circuits. All active tests are carried out in just one step, including functional testing and displaying the RMS values. The high-contrast LC display clearly shows selection menus, available settings, limits, measurements, notes, error messages, and I/O settings. Plain text operation with schematic circuit diagrams as well as red and green signaling LEDs for evaluation of measured values simplify testing. The tester runs on 230 VAC mains voltage. The tested device is connected via the 16 A test socket. METRALINE PAT ensures safe testing by checking the protective ground conductor of the power connection, checking the tested device for short circuits, and triggering an automatic shutdown in case of dangerous leakage currents. The tester features USB and Bluetooth interfaces to transmit measurement and test data. This enables operators using the ELEXONIQ METRALINE app (available in the Google Play store) to feed measured values via Bluetooth to the IZYTRONIQ testing software that supports multiple devices.

Introducing the METRALINE series, Gossen Metrawatt provides a new family of professional measuring and testing equipment that offers high functionality and reliability at an optimized price–performance ratio. The new product line includes three digital multimeters with different feature sets. All of these are equipped with automatic-blocking sockets, which prevent the incorrect connection of measuring lines and thus provide complete protection for the user. The DM 62 is designed as a TRMS multimeter with true value measurement up to 2 kHz for demanding measurement tasks in AC and DC networks. It covers a voltage range of 100 µV…1000 V and a current measurement range of 10 µA…10 A and furthermore provides all necessary functions for resistance, temperature, frequency, capacitance, and duty cycle measurement, as well as continuity and diode testing. Another model, the DM 61, is a universal multimeter with an adjustable clip for connecting a current clamp. Gossen Metrawatt’s WZ1001 current clamp, for instance, is optimally tailored to the DM 61. Both these multimeters are secure according to measuring categories CAT IV (300 V) or CAT III (600 V). They feature automatic and manual measurement range selection as well as a backlit dual digital display with an analog scale. The third model, the DM 41, is a non-TRMS multimeter with a versatile range of functions for all standard measuring tasks. In addition, the METRALINE series comprises a DIN VDE 0701-0702 PAT device tester for testing portable equipment, which works with the new IZYTRONIQ testing software via an Android app, as well as a digital a low-resistance ohmmeter for testing protective conductors, ground conductors, and equipotential bonding conductors. Three handy, battery-powered instruments for examining protective measures, specified for checking insulation resistance, RCDs, and loop resistance, respectively, complete the product line. These lightweight testers can be comfortably carried in a belt pouch and are ideal for electricians who have to assure the functional safety of systems.

Gossen Metrawatt now provides PROFITEST MASTER instruments with the new IZYTRONIQ testing software. The upgrade enables visualization, data management, and audit-proof documentation of all test events across devices. For the first time, measurement and test data from different testers and multimeters can be collated in one inspection. Objects and places are assigned via drag and drop. Therefore, even complex procedures become very easy, for instance assigning datasets to other locations such as lots, buildings, levels, and rooms. Individual test structures can be directly uploaded to the test instrument. Control options also include practical features such as a push/print function to further simplify the transmission of measured values with all relevant characteristics. The Business Starter version installed by default in all PROFITEST MASTER instruments can be upgraded be at any time as needed. Additional Business versions are available, as well as network-enabled Enterprise versions. This expands the capabilities of the CAT IV devices. The series is designed for testing and measuring tasks in all AC and three-phase networks with voltages from 65 V to 500 V and frequencies from 15.4 Hz to 420 Hz. The systems support all tests according to DIN VDE 0100-600 / DIN VDE 0105-100 to check the effectiveness of protection measures in electrical installations in private homes, commercial buildings, and industrial facilities. On top of basic standard tests, PROFITEST MASTER offers numerous additional measuring functions and meets the requirements for acceptance tests and periodic inspections in fixed electrical installations. The devices‘ ergonomic design and user-friendly operation simplify the selection and setup of test sequences. The current measuring method and values are always clearly shown on the integrated illuminated display.

For SECUTEST instruments from Gossen Metrawatt, the manufacturer’s new IZYTRONIQ software is now included in supply. The SECUTEST series comprises various models for testing the electrical safety of electrical devices and welding units up to 400 V. Special variants are available for type testing of medical devices during production as well as for periodic inspections according to IEC/EN 62353 and IEC/EN 60601: SECULIFE ST BASE, ST BASE25, and ST PRO. The instruments feature pre-programmed test sequences with automatic evaluation per VDE 0701-0702, IEC/EN 62353 (VDE 0751), and IEC/EN 60974-4 (VDE 0544-4). In addition, users can define their own test sequences to meet specific standards such as IEC 60601, 61010, 60335, 60204. The software upgrade expands the scope of measuring, testing, and integral metering capabilities, since IZYTRONIQ adds new device functions and methods of measurement. In addition to an exceptional function range, the software features intuitive operation and a contemporary design for up-to-date standards-compliant data management. Users can simply drag and drop test objects and locations. Even complex operations such as assigning existing objects to other sites, buildings, levels, or rooms are easy to accomplish. Users can freely switch between table, tree, and index card views in portrait or landscape formats as well as between touch and mouse operation. Smart features for highlighting or hiding specific tools and workspaces make it easy to select the right function in everyday operation. User-friendly control options also include the practical remote mode and a push/print function, which simplify the transmission of measured values with all relevant characteristics. Furthermore, the software now enables the collation of measurement and test data from different testers and multimeters in one inspection as well as their audit-proof documentation. The default Business Starter version installed in all SECUTEST instruments can be upgraded at any time as needed. Users can choose from additional Business versions or network-enabled Enterprise versions. All existing data is simply carried over.

The GMC-Instruments group and its Gossen Metrawatt brand have launched a new cloud platform for secure inspection data management that holds up to legal scrutiny. The GMC-Instruments cloud offers a suite of applications and services for structured, comprehensive test and measurement data acquisition, archiving, and documentation. It greatly facilitates standards-compliant electrical safety inspections. Incorporating the IZYTRONIQ, ELEXONIQ, and VIZIONIQ modules, the cloud platform covers all current requirements of a modern, future-proof, upgradeable testing regime. Measured values and test data from various devices can be easily combined into one inspection. Users can view these schemes remotely at any time. Tiered access rights can be set up. Connection to this cloud saves costly investments in IT infrastructure and storage capacity. It ensures maximum data availability and secure communications through SSL-encrypted data transfer. The solution is based on the new cloud version of the IZYTRONIQ test software, which enables multiple users to easily access all inspection data, facilities, and documentation materials. Team access, shared execution of test sequences, and rights management tailored to employees‘ qualifications make the entire testing process more flexible. In addition, the ELEXONIQ app enables taking rapid inventories of customers, sites, and objects using smartphones, tablets, or notebooks. App users can directly synchronize data with the cloud without the IZYTRONIQ inspection software. They can also scan bar codes and take photos and assign them to objects. As a third module, GMC-I has integrated the web-based VIZIONIQ customer portal. This tool enables users to share all kinds of data with customers in a clearly structured form without time-consuming configuration: test results, reports, documentation, and attachments. Test technicians and electricians can now subscribe to the new GMC-I cloud service for a monthly fee.

Gossen Metrawatt now provides PROFITEST MASTER instruments with the new IZYTRONIQ testing software. The upgrade enables visualization, data management, and audit-proof documentation of all test events across devices. For the first time, measurement and test data from different testers and multimeters can be collated in one inspection. Objects and places are assigned via drag and drop. Therefore, even complex procedures become very easy, for instance assigning datasets to other locations such as lots, buildings, levels, and rooms. Individual test structures can be directly uploaded to the test instrument. Control options also include practical features such as a push/print function to further simplify the transmission of measured values with all relevant characteristics. The Business Starter version installed by default in all PROFITEST MASTER instruments can be upgraded be at any time as needed. Additional Business versions are available, as well as network-enabled Enterprise versions. This expands the capabilities of the CAT IV devices. The series is designed for testing and measuring tasks in all AC and three-phase networks with voltages from 65 V to 500 V and frequencies from 15.4 Hz to 420 Hz. The systems support all tests according to DIN VDE 0100-600 / DIN VDE 0105-100 to check the effectiveness of protection measures in electrical installations in private homes, commercial buildings, and industrial facilities. On top of basic standard tests, PROFITEST MASTER offers numerous additional measuring functions and meets the requirements for acceptance tests and periodic inspections in fixed electrical installations. The devices‘ ergonomic design and user-friendly operation simplify the selection and setup of test sequences. The current measuring method and values are always clearly shown on the integrated illuminated display.

For SECUTEST instruments from Gossen Metrawatt, the manufacturer’s new IZYTRONIQ software is now included in supply. The SECUTEST series comprises various models for testing the electrical safety of electrical devices and welding units up to 400 V. Special variants are available for type testing of medical devices during production as well as for periodic inspections according to IEC/EN 62353 and IEC/EN 60601: SECULIFE ST BASE, ST BASE25, and ST PRO. The instruments feature pre-programmed test sequences with automatic evaluation per VDE 0701-0702, IEC/EN 62353 (VDE 0751), and IEC/EN 60974-4 (VDE 0544-4). In addition, users can define their own test sequences to meet specific standards such as IEC 60601, 61010, 60335, 60204. The software upgrade expands the scope of measuring, testing, and integral metering capabilities, since IZYTRONIQ adds new device functions and methods of measurement. In addition to an exceptional function range, the software features intuitive operation and a contemporary design for up-to-date standards-compliant data management. Users can simply drag and drop test objects and locations. Even complex operations such as assigning existing objects to other sites, buildings, levels, or rooms are easy to accomplish. Users can freely switch between table, tree, and index card views in portrait or landscape formats as well as between touch and mouse operation. Smart features for highlighting or hiding specific tools and workspaces make it easy to select the right function in everyday operation. User-friendly control options also include the practical remote mode and a push/print function, which simplify the transmission of measured values with all relevant characteristics. Furthermore, the software now enables the collation of measurement and test data from different testers and multimeters in one inspection as well as their audit-proof documentation. The default Business Starter version installed in all SECUTEST instruments can be upgraded at any time as needed. Users can choose from additional Business versions or network-enabled Enterprise versions. All existing data is simply carried over.

The GMC-Instruments group and its Gossen Metrawatt brand have launched a new cloud platform for secure inspection data management that holds up to legal scrutiny. The GMC-Instruments cloud offers a suite of applications and services for structured, comprehensive test and measurement data acquisition, archiving, and documentation. It greatly facilitates standards-compliant electrical safety inspections. Incorporating the IZYTRONIQ, ELEXONIQ, and VIZIONIQ modules, the cloud platform covers all current requirements of a modern, future-proof, upgradeable testing regime. Measured values and test data from various devices can be easily combined into one inspection. Users can view these schemes remotely at any time. Tiered access rights can be set up. Connection to this cloud saves costly investments in IT infrastructure and storage capacity. It ensures maximum data availability and secure communications through SSL-encrypted data transfer. The solution is based on the new cloud version of the IZYTRONIQ test software, which enables multiple users to easily access all inspection data, facilities, and documentation materials. Team access, shared execution of test sequences, and rights management tailored to employees‘ qualifications make the entire testing process more flexible. In addition, the ELEXONIQ app enables taking rapid inventories of customers, sites, and objects using smartphones, tablets, or notebooks. App users can directly synchronize data with the cloud without the IZYTRONIQ inspection software. They can also scan bar codes and take photos and assign them to objects. As a third module, GMC-I has integrated the web-based VIZIONIQ customer portal. This tool enables users to share all kinds of data with customers in a clearly structured form without time-consuming configuration: test results, reports, documentation, and attachments. Test technicians and electricians can now subscribe to the new GMC-I cloud service for a monthly fee.

Gossen Metrawatt has launched the new, modular SU1604 summator for energy control systems (ECS). It can be expanded to up to 64 processing channels. Users can assign electrically isolated S0 counter inputs for processing pulse-shaped S0 input signals to individual channels. They can also choose to assign LON devices, with all the added benefits of this easy-to-wire, electrically isolated interface featuring polarity reversal protection. Energy or consumption data are collected in lockstep with the energy supplier’s measurement cycle and added up over defined time periods and a programmable interval, and saved along with the corresponding maximum values. In addition to the interval-based data list, up to four recorders with up to 64 channels and different time bases starting from one second can be defined. Each channel can be parameterized for any measured data such as analog, power, and consumption values in the interval or for running totals. Measured data comprise 32-bit float values or 64-bit double values saved to 100 MB of rolling storage space. This autonomous database for all electrical and non-electrical energy and consumption data enables visualization, consumption optimization, and cost-related billing. The summator features an RS485 and an RS232 interface as well as an Ethernet port for remote access to device data via TCP/IP. Four TCP/IP sockets with ECL access can be used simultaneously, and two of these sockets can be used for ECS-LAN networking. The U1604 summator is suitable for supplementing or replacing ECS summators from the U1600, U1601, U1602, and U1603 series. Thanks to intelligent evaluation electronics with the system’s own programming language, the summator can also be used for customer-specific calculation, evaluation, monitoring, and optimization of energy values without integration into an ECS.

Because every inch is precious in a control cabinet, Gossen Metrawatt has now launched a new generation of MID calibrated meters built to extremely compact dimensions. In a 4 HP design, which corresponds to an enclosure width of merely 72 mm, the new ENERGYMID provides a unique range of functions in its device class. At the same time, its small size allows the meter to be easily mounted on any 35 mm DIN rail in any position. Installation and commissioning are safe and easy thanks to the integrated connection fault diagnosis function. Its backlit panel, which very clearly displays all selected measurement data, alerts users to any installation errors via a distinctive change of color in the display. Depending on the selected model, the units record not only energy consumption but up to 33 additional parameters for cost accounting according to the standards of the Measuring Instrument Directive 2014/32/EU. These parameters include reactive energy, apparent power, neutral conductor current, power factor, frequency, power supply and more. In addition, the devices monitor power quality through Total Harmonic Distortion (THD). Measured values are transmitted via pulse through standardized or freely programmable S0 interfaces. The meter is available with optional bus interfaces for M-Bus, LON, BACnet, and MODBUS RTU/TCP to facilitate data transmission and remote readout. ENERGYMID meters come with three years manufacturer’s warranty from Gossen Metrawatt and are offered at an attractive price. They are suitable for 2-, 3- and 4-wire systems with current transformer connection (1(6) A) and input voltages ranging from 100 to 500 V. They can be supplied as pre-configured standard models or in custom versions with an individually selected range of features and interfaces.

Nuremberg, Germany – Measurement technology specialist Gossen Metrawatt launches IZYTRON.IQ, a completely new test software that enables visualization, management, and revision-proof documentation of all test events across various devices. For the first time, measurement and test data from different testers and multimeters can be collated in one inspection. An intuitive and stylish GUI provides quick access to all functions. Intelligent highlighting and hiding functions ensure that users are pointed to those tools and sections that are pertinent to their respective tasks. Usability is further enhanced through meaningful icons and tree views of complex database relations. Users can individually adjust the viewing options and switch between table, tree, and index card views in portrait or landscape formats. They can also switch between touch and mouse operation. Objects and places are assigned via drag and drop. Therefore, even complex procedures become very easy, for instance assigning datasets to other locations such as lots, buildings, levels, and rooms. Control options also include such practical features as remote mode and a push/print function. These further simplify the transmission of measured values with all relevant characteristics. Flagged datasets with a GUID identifier ensure maximum data integrity. Gossen Metrawatt offers different, scalable software versions for trade, industry, and training purposes. Business-grade single-user licenses are available in three versions with a different scope of functions. Upgrades are possible at any time. All versions come with an integrated SQLite database. In addition, there are network-enabled Enterprise versions with floating licenses that use a Microsoft SQL database. Included functions for the latter comprise tiered access rights and data replication for online and offline applications, allowing for simultaneous use in testing teams.

Nuremberg, Germany – Gossen Metrawatt announces the launch of its newly developed METRAHIT generation of handheld multimeters. The rugged, compact units for field use feature an outstanding functional range that is unique in the world. Four specialized variants cover all relevant safety inspection tasks and multimeter functions for troubleshooting and diagnostics on electric vehicles and machines. The METRAHIT IM XTRA is the only mobile measuring device that also allows for 4-wire measurements in the milliohm range, enabling precise detection of minimal resistances with resolutions up to 1 µO. Additional integrated functions include insulation resistance inspections up to 1000 V, 2-wire Rlow measurements with a 200 mA test current according EN 61557-4/VDE 0413-4, and 1000 V impulse voltage tests with an optional COIL adapter for detecting interturn short-circuits in electric machines. Moreover, the all-in-one devices perform TRMS current and voltage measurements up to 10 or 100 kHz, precision temperature measurements with RTD and TC-K sensors, capacitance measurements, as well as measurements of the polarization and absorption index. To ensure protection from high short-circuit currents in electric vehicles, the multimeters now meet the demands of measurement categories CAT III 1000 V and CAT IV 600 V. The user-friendly design optimized for one-hand operation ensures easy handling of the devices. A 3.5″ color graphics TFT screen neatly displays test sequences, measured values, and help texts. Test sequences and up to 300,000 readings can be saved in the unit and directly transmitted to the test software by means of a push/print function. Bluetooth and WiFi data communication interfaces are integrated. A USB connection is available with an optional power module. In mobile mode, the device runs on a quick-change lithium-ion battery. The battery can be recharged via micro USB. Gossen Metrawatt also supplies new generation METRAHIT IM XTRA multimeters with a special design for the automotive and electric car sector.

Gossen Metrawatt, a leading measurement and testing technology specialist, is celebrating its 111th anniversary in 2017. The company was originally founded by physicist Siegfried Guggenheimer, as an enterprise for the development and production of electric measuring instruments in Nuremberg, Germany, in 1906. In addition to measuring and test equipment, GMC-I Messtechnik GmbH, its brand Gossen Metrawatt, and affiliated companies in the GMC Instruments group stand for intelligent solutions for detailed, standard-compliant energy management, monitoring and analysis of grid quality, and inspection of data and communication networks. „The safe use of electric power has been and remains at the core of our brand. We manufacture future-proof measuring and testing equipment that meets the needs of digitization and of the growing interconnection of power supply and communication systems,“ says CEO Dr. Hans-Peter Opitz. New generations of meters and measurement and system testing devices fulfill current standards as well as demanding requirements relating to safety, accuracy, data transfer, and documentation. The product portfolio includes high-end, individually tested energy meters for transparent consumption data acquisition in industrial, commercial, medical, and building technology, and in private households. The measurement specialist also supplies various lines for testing electrical safety up to the high voltage range. The GMC-I group operates an officially approved calibration laboratory and several DakkS-accredited calibration centers, which carry out DakkS, ISO, and factory calibrations for almost all electrical and optical parameters.

In order to enhance the energy efficiency of buildings, infrastructure and industrial facilities, getting a transparent record of energy consumption is absolutely vital. However, densely packed equipment and distributed installations often complicate the integration of efficient measurement technology. Measurement specialist Gossen Metrawatt therefore now introduces ENERGYSENS, a new modular sensor system for precise energy consumption metering in accordance with precision class 1 in the DIN EN 60688 or DIN EN 62053-21 standards. The new measuring system comprises the slim ENERGY EScom basic module, which is only 2 HP wide, and up to 10 highly compact ENERGY ES sensor units that are available in four versions with 3 or 12 measuring inputs for current ratings of up to 40 A or 80 A. This allows for a flexible connection of up to 120 measuring points with a connection length up to 5 m to each base module. This very versatile solution is also very suitable for tight installation spaces in existing energy distribution boxes. Mounting the devices is very easy. In 50/60 Hz AC low-voltage systems, they can monitor the actual consumption values for effective power, energy, current, voltage and frequency. Moreover, by monitoring the phase load, ENERGYSENS also contributes to preventive maintenance and keeping downtime to a minimum. The sensors feature an extremely low profile with a very slim 13 mm. They are mounted onto the fuses. Measured values are transmitted to the base module via plug-on ribbon cable. Universal Modbus TCP and MODBUS RTU interfaces ensure fast data transfer in a variety of system environments. For an easy system integration without any programming, Gossen Metrawatt provides a free configuration software that is available for download on the company’s website. In addition to the sleek design, ENERGYSENS also excels in term of minimal power consumption, in contrast to much more power-hungry other products on the market.

Measuring technology for testing the electrical safety in sterile or hygienically sensitive areas – ranging from hospitals, laboratories, or medical practices to production facilities in the pharmaceutical or food sector – are subject to particularly strict regulations. For such environments, measuring technology expert Gossen Metrawatt has developed SECULIFE HIT AM, a digital TRMS multimeter featuring an anti-microbial design. The ergonomically designed hand-held device enables TRMS AC and AC + DC measurements, irrespective of the signal shape, for voltages and currents up to 20 kHz. 23 multimeter functions provide secure and reliable measurements for all required inspection tasks, including current measurement from 100 mA up to 10 A, voltage, capacitance and resistance measurement, and diode and continuity tests. In addition, a 1 kHz low pass filter can be switched on to measure e.g. the motor voltage at electronic frequency converters. Measurement of 5 V square wave signals is also supported. For enhanced safety, the housing, cables, and measuring probes are made from an anti-microbial material composition that counteracts microbial colonization. The multimeter comes with IP65 ingress protection. It features an illuminated display with digital and analog measurement indicators, which show fixed values as well as dynamic measurement curves with great accuracy. Measured parameters can be adjusted via a rotary switch and a function key. The measuring range automatically adapts to the reading, but can also be manually selected whenever necessary. A single connection port is used for all current measuring ranges, which completely eliminates any potential confusion. Up to 40 values per second can be automatically stored. The total storage capacity is sufficient for more than 15,000 measurements. The device is approved for CAT IV measurements up to 600V and is extremely safe to operate: in addition to a high-voltage sensor that ensures the input signal is safe to touch, the device features automatic socket blocking, which prevents the incorrect connection of cables or selection of the wrong measured parameters.

Gossen Metrawatt now provide their compact, high-performance ENERGYMID energy meters in two versions designed for direct connection. These models require no external current and voltage transformers, which saves installation space as well as expenses. The recently launched EM 2281 meter measures energy consumption directly in 2-wire AC systems with 230 V voltage. The second model now introduced by the measuring technology experts, the EM 2289 meter has been designed for 4-wire three-phase current with ratings up to 80 A and an input voltage of 400 V. Like all devices in this new generation meter range, the two direct measuring models are pre-calibrated according to MID standards and generate power consumption records and power feed data for differentiated cost accounting. With an extensive range of functions comprising not only energy consumption, but also up to 33 additional parameters depending on the selected model, the EM 2281 and EM 2289 meters are uniquely positioned in their market segment. For instance, they can be used to measure reactive energy, apparent power, neutral conductor current, power factor, frequency and power supply, and will additionally monitor power quality through Total Harmonic Distortion (THD). Users can choose from a range of standard or freely programmable outputs to measure value transmission via pulse. The manufacturer also offers optional interfaces for M-Bus, LON, BACnet, and MODBUS RTU/TCP to facilitate flexible network integration and remote readout. With a width of merely 4 pitch units, the new generation meters are also extremely compact. They can be mounted on 35 mm DIN rails in any orientation in a cabinet. A backlit display clearly shows the selected measurement data, facilitates the monitoring of connection parameters and alerts users to phase failure, overload and installation errors by changing the display color.

Nuremberg – The new PROFITEST PRIME for standard-compliant testing of electrical installations is due to be launched by Gossen Metrawatt in spring 2017. This instrument combines state-of-the-art measurement technology with a unique set of features. It is suitable for almost any inspection task in machinery and switchgear construction, industrial and IT networks, wind turbines, photovoltaic systems, and electric charging stations. It is the only product of its kind with a large-scale test range that has been expanded to include 690 V AC and 800 V DC networks. Moreover, it is unique in featuring various newly developed test procedures: for the first time, it is possible to loop test in networks secured with type B RCD protection switches. Other new test procedures include innovative measurement methods to test ISO monitors up to 690 V and AC/DC sensitive RCDs up to 440 V in IT networks. All measurements can be made while leaving the measuring lines in place. Test prods and fuses can be changed quickly. Coded connectors prevent handling errors. Modern data management has been implemented to facilitate the creation of plant structures for protocols and other documentation. In addition to predefined automated sequences that enable fast implementation of various measurement tasks, custom test sequences can be programmed. PROFINET PRIME is the only device in its class that can be operated on battery power in case the regular power supply is unavailable. The battery charge is sufficient for up to a thousand measurements, giving users great flexibility. In addition to the standard version for low voltage installations up to 1,000 V AC / 1,500 V DC, the PROFITEST is available in two enhanced versions that additionally include high-voltage tests with 5,000 V DC or 2,500 V AC. The latter also features a function for pulsed continuous measurements to identify defective cable insulation. All models feature Bluetooth and USB interfaces for bi-directional data exchange, e.g. to keep test result logs in a PC software. An RS232 interface is integrated to enable the connection of bar code or RFID scanners and various sensors. Extensive accessories and attractive package solutions are also available.

Nuremberg – Measurement specialist Gossen Metrawatt introduces ENERGYMID, a new generation of high-performance, extremely compact power meters. The new devices feature scalable functionality and are available for 2-, 3- or 4-wire networks with a transformer connection (1(6) A) and input voltages ranging from 100 to 500 V. They come pre-calibrated according to the MID standard and provide power consumption and power feed data for differentiated cost accounting. In addition to energy consumption and depending on the specific meter model, up to 33 additional parameters can be measured. These include reactive energy, apparent power, neutral conductor current, power factor, frequency, and energy fed into the network. Network quality is also monitored via THD current and voltage measurement. The ENERGYMID handles up to eight different rates for electricity and is therefore well-equipped for future structural pricing changes. Measured values are transmitted via pulse through standardized or freely programmable S0 interfaces. LON, M-Bus, MODBUS-RTU/-TCP or BACnet interfaces are optionally available as well for data transfer and remote readout. An integrated ring buffer ensures local data backup. The meters feature a high power density and are only four 18 mm module units wide. These extremely compact devices can be mounted on 35 mm DIN rails in any position. A backlit display clearly shows the selected measurement data, facilitates the monitoring of connection parameters and alerts users to installation errors by changing the display color. A parameter lock and sealed cover ensure the devices cannot be tampered with. The new ENERGYMID is available at a competitive price and with a manufacturer’s warranty of three years.
