RAFI expands MICON 5 micro-switch series

With the MICON 5 S, MICON 5 SL, and MICON 5 SAFETY series, RAFI has launched a new generation of robust, ultra-small tactile switches.

full text

With the MICON 5 S, MICON 5 SL, and MICON 5 SAFETY series, RAFI has launched a new generation of robust, ultra-small tactile switches. The extremely compact micro-switches measure just 5.1 x 6.4 x 3.85 mm. Thanks to their optimized sealing system, they achieve IP67 degree of protection and can therefore be installed on PCBs protected by casting, painting, or nanocoating. The extreme temperature resistance from -40°C to +125°C meets current automotive industry standards. High-quality gold contacts ensure permanent switching reliability. The micro-switches are available for operating forces of 1.5 N to 8 N as well as in the extremely long-life MICON 5 SL version. With an operating life of up to ten million actuation cycles, the SL switches are designed for tough applications, e.g. in joysticks and other control devices subject to high stress. The third option in the range is an enhanced-safety version. With identical dimensions, the MICON 5 SAFETY series incorporates two potential-free, separate NC and NO contacts. Due to the two-channel contact system, these models are ideal for safety-critical applications that meet the functional safety requirements of IEC 61508, DIN EN ISO 13849, IEC 62061, IEC 60601, DIN EN ISO 25119, DIN EN 50128, or ISO 26262. Characteristic of all MICON 5 variants is their distinctive tactile feedback. The model series are available with SMT and in some versions THT. The media-resistant design makes them ideal for automated PCB assembly and sealing. There is also an extensive range of accessories with compatible plungers, keycaps, and illumination solutions for all use cases.

date: 2023-04-25 | characters: 1625 | download: document, picture 1

RAFI

RAFI Group invests in the future

RAFI is currently investing in two major projects: In April 2023, the company will begin construction of a new building in Bad Waldsee with infrastructure that is both energy-efficient and low-consumption. The new facility is a combined, state-of-the-art office and production building.

full text

RAFI is currently investing in two major projects: In April 2023, the company will begin construction of a new building in Bad Waldsee with infrastructure that is both energy-efficient and low-consumption. The new facility is a combined, state-of-the-art office and production building. It will house the operating equipment for plastics and automatic machine production, metal processing, tool and die making, and tool and die development. A number of classrooms and the facilities for basic training in metalwork will be combined into an impressive apprenticeship, teaching, and further training center. “These projects represent an investment in the sustained further growth of the entire RAFI Group,” explains Dr. Lothar Seybold, CEO of the RAFI Group. CFO Lothar Arnold adds: “The construction of a new production plant in Bad Waldsee is a clear statement of commitment to the region as a business location. It creates new, crisis-proof jobs here.”
The second major project is the revamp of the location in Berg. It was launched in 2022 and RAFI has now completed the first construction phase. As part of its growth strategy, RAFI is investing a sum in the high two-digit millions for the three-year renovation and energy-saving modernization project. It involves successively fitting the buildings with new, climate-friendly roofs, façades, and glazing. The physical effects are expected to deliver energy savings of up to 45% and a significant reduction in CO2 emissions of around 340 tons per year. The first construction phase for Building A has been successfully completed. Now the nine-story block has new external insulation plus a rear-ventilated façade made of certified recycled aluminum. From an energy standpoint, all components are designed for maximum reduction in CO2 emissions.

date: 2023-02-22 | characters: 1798 | download: document, picture 1, picture 2

RAFI

RACON ST: New generation of tactile switches from RAFI

RAFI’s tried-and-tested RACON 8 and RACON 12 S tactile switch series are now available in a temperature-optimized version intended for various PCB protection procedures.

full text

RAFI’s tried-and-tested RACON 8 and RACON 12 S tactile switch series are now available in a temperature-optimized version intended for various PCB protection procedures: Thanks to the additional sealing system, the new RACON ST tactile switch series (sealed & extended temperature range) is ideal for casting, lacquering and nanocoating of correspondingly equipped PCBs. In addition, RACON ST sets itself apart from conventional switches thanks to its 35°C higher maximum operating temperature and, with a temperature resistance of -40°C to +125°C, it also meets the current standards of the automotive industry. None of the usual RACON tactility is lost due to the extended durability features. Like the existing series of key switches, the ST switches have compact dimensions of 12 mm x 12 mm or 8.4 mm x 8.4 mm and are available in SMT or THT versions. High-quality gold contacts ensure permanent switching reliability. To meet the various demands of tactile feedback, the switches are available in types for operating forces of 2.5 N to 9.7 N. For applications underneath membranes, the range of accessories includes round or square plungers in twelve lengths ranging from 1.4 mm to 7.6 mm.

date: 2022-11-16 | characters: 1193 | download: document, picture 1

RAFI

MICON 5 SAFETY: Micro key switch with two-channel contact system

MICON 5 tactile switches from RAFI are now also available in a new MICON 5 SAFETY version with a two-channel contact system.

full text

MICON 5 tactile switches from RAFI are now also available in a new MICON 5 SAFETY version with a two-channel contact system. With a base of just 5.1 x 6.4 mm and a height of 3.85 mm, MICON 5 SAFETY key switches come in the same dimensions as MICON 5 key switches, but integrate two potential-free, separate NC and NO contacts. This means the micro key switches enable an especially cost-effective and space-saving design in applications that comply with functional safety standards such as DIN EN IEC 61508 (basic functional safety standard), DIN EN ISO 13849 (safety-related parts of control systems), DIN EN IEC 62061 (safety of control systems), DIN EN IEC 60601 (medical electrical equipment), DIN EN ISO 25119 (control systems for agricultural and forestry machines), DIN EN 50128 (rail applications), or ISO 26262 (road vehicles). Due to the optimized sealing system, MICON 5 SAFETY key switches comply with IP54 and/or IPx7 degrees of protection. With a temperature resistance of -40°C to +125°C, they also meet the current requirements of the automotive industry. For PCB assembly, the key switches feature SMT connection and are suitable for casting, painting, and nano-coating. Just like RAFI’s standard versions, MICON 5 SAFETY key switches feature a gold-contact system for reliable switching, excellent tactility, and a long operating life. The key switches are available for various operating forces and, depending on the version, they achieve up to one million operations. Thanks to the identical dimensions of the two ranges, the extensive MICON 5 accessory program of plungers and keycaps is equally suitable for MICON 5 SAFETY key switches.

date: 2022-10-26 | characters: 1658 | download: document, picture 1

RAFI

RAFI Electronics expands production capacities

Last December, the RAFI Group’s Chinese branch, RAFI Electronics, moved into its new production facility in Shanghai. In the new factory in Quingpu, RAFI Electronics has a production area of 7,800 m˛, of which 4,600 m˛ is a clean room area for the production of electronics using SMT and THT assembly.

full text

Last December, the RAFI Group’s Chinese branch, RAFI Electronics, moved into its new production facility in Shanghai. In the new factory in Quingpu, RAFI Electronics has a production area of 7,800 m˛, of which 4,600 m˛ is a clean room area for the production of electronics using SMT and THT assembly. The HMI specialist will use five SMT lines to produce mainly electronics for the medical technology, robotics, and automotive industries. The other 3,200 m˛ of production space is allocated to product assembly. With cutting-edge energy supply technology, RAFI Electronics also meets its green responsibilities: Installed on the roof is a solar power system with an area of 2,200 m2 and a capacity of 200 KVA. It powers a micro grid with an energy storage system.
On the opening date on December 22, 2021, Zhu Mingfu, Director of the Standing Committee of the People’s Congress of Qingpu District, visited the new factory and praised the sustainable development of the industrial park, which he called a win-win situation for all stakeholders. Thanks to the new factory, RAFI Electronics can not only considerably expand its production capacities, but also moves closer to the Asian markets. Simultaneously, RAFI customers in Europe and the USA benefit from the good price-performance ratio the manufacturer achieves by purchasing components in China. On this basis, RAFI with its production locations in Germany, Italy, Hungary, the USA, and China, can offer ideal solutions for every customer requirement.

date: 2022-02-16 | characters: 1508 | download: document, picture 1

RAFI

RAFI Hungaria turns 30

On the occasion of its 30th anniversary this year, RAFI Hungaria Kft. looks back on three decades of success. In 1991, RAFI founded RAFI-BBP in Mezotúr, Hungary, to expand its assembly capacities for electromechanical operating elements. Even in its first year, the number of employees increased from 5 to 21.

full text

On the occasion of its 30th anniversary this year, RAFI Hungaria Kft. looks back on three decades of success. In 1991, RAFI founded RAFI-BBP in Mezotúr, Hungary, to expand its assembly capacities for electromechanical operating elements. Even in its first year, the number of employees increased from 5 to 21. Starting in 1995, RAFI-BBP gradually expanded its activities to include the manufacture of electronic and opto-electronic assemblies. The company also introduced quality management in compliance with ISO 9002. After continuous expansion of the manufacturing facilities and soldering systems, the company also added assembly of electronics products for the automotive industry to its range. In 2000, a new production unit was built, doubling the operating area. At the same time, the company adopted a process-oriented QM system according to EN ISO 9001:2000. Over the following years, the company expanded its production capacities by installing new high-performance assembly lines for electronic assemblies as well as a third production unit with a total useful area of 2,200 m˛. It also introduced a quality management system for medical products that complies with ISO 13485. Today, RAFI Hungaria operates production areas totaling 7,760 m˛ and has more than 500 employees. There has always been a focus at the company on training and further training to ensure a qualified current and future workforce. This prompted it to join forces with local technical school Teleki Blanka to establish a highly practical training program for electronics technicians. Furthermore, RAFI Hungaria cooperates with the University of Debrecen in its dual-studies program by offering opportunities for works students.

date: 2021-12-15 | characters: 1712 | download: document, picture 1, picture 2

RAFI

BeeWaTec exclusive partner for KIS.ME since October

In October, RAFI and BeeWaTec agreed on a partnership for the sale of RAFI’s innovative KIS.ME communication and process control system. BeeWaTec is a solution provider for lean manufacturing, agile production and Industry 4.0. In the future, its customers will be able to directly order all KIS.M

full text

In October, RAFI and BeeWaTec agreed on a partnership for the sale of RAFI’s innovative KIS.ME communication and process control system. BeeWaTec is a solution provider for lean manufacturing, agile production and Industry 4.0. In the future, its customers will be able to directly order all KIS.ME hardware components and services, including application-specific system configuration, from BeeWaTec. KIS.ME stands for “Keep it simple. Manage everything”. The smart Plug&Play solution enables fast and easy digitalization of previously unconnected work, logistics, and production areas. The system is based on WLAN-capable control boxes and signal lamps with integrated I/Os which are networked via the KIS.MANAGER web platform. They are configured to the specific application in each case using simple logical rules. This enables customers to implement transparent signaling processes in previously non-digitalized production or logistics applications. It also allows easy integration of manual workplaces, remote delivery zones and older machines into the cloud-based control system. The data from these application areas is then captured in the cloud system and displayed in KIS.MANAGER for analysis. KIS.ME users can access KIS.MANAGER through a central web account at RAFI. As an exclusive partner of RAFI, BeeWaTec can offer its customers this service together with the required hardware from a single source. “We are delighted to have gained such a renowned specialist for manufacturing systems as BeeWaTec to be our sales partner” explains Axel Zauke, Key Account Manager at the RAFI Group. “The interest of BeeWaTec in our product also shows that it offers the right solution for many digital retrofitting jobs.” “In our view, previously no convincing solutions were available for the efficient collation of data from unconnected production or logistics areas and its transfer to the control system,” says Joachim Walter, COO of BeeWaTec. “KIS.ME closes this gap. Its ingenious concept also makes implementation very easy.”

date: 2021-12-08 | characters: 2032 | download: document, picture 1

RAFI

RAMO control components in floor cleaners

During the typical working day of a floor cleaner, the control technology must be able to withstand a good deal of wear and tear and, in addition to mechanical stress, must also withstand many a rustic actuation. That’s why Dr.

full text

During the typical working day of a floor cleaner, the control technology must be able to withstand a good deal of wear and tear and, in addition to mechanical stress, must also withstand many a rustic actuation. That’s why Dr. Gansow Gmatic AG uses robust, easy-to-install switches from the RAFI RAMO 22 series as the control units in its high-quality Gmatic and Rotan scrubber dryers. The actuators, sized for an installation opening with a diameter of 22.3 mm, are very easy to install and connect. As standalone solutions in the completely enclosed mono-housing, they achieve a high degree of protection up to max. IP69 without the need for further seals. Thanks to direct wiring via M12 terminals, no time-consuming individual wiring is required. Correct connection is possible without specialist knowledge of electrical engineering. Service and maintenance work is also reduced, because the connections can be easily disconnected and reconnected as required. Switching states and settings are indicated clearly by signal lamps, illuminated switches and twist grip labels. The energy-efficient LED technology is robust and lasts for the lifetime of the machine.

date: 2021-12-01 | characters: 1166 | download: document, picture 1

RAFI

E˛MS for low-power applications

Today, the energy consumption of heating radiators is usually recorded and calculated fully automatically using smart meters. These devices must function maintenance-free and without battery replacement over an operating life of ten years.

full text

Today, the energy consumption of heating radiators is usually recorded and calculated fully automatically using smart meters. These devices must function maintenance-free and without battery replacement over an operating life of ten years. As a provider of electronic engineering and manufacturing services (E˛MS), RAFI produces large quantities of these high-value electronic meters and additionally supports metering companies in optimizing designs for low-power applications. To ensure its customers can rely on the maintenance-free functioning of its devices, RAFI insists on appropriately long storage and supply periods. This is why the E˛MS service provider exclusively procures its lithium batteries for low-power applications from suppliers who guarantee an extended minimum service life of 12.5 years. RAFI additionally carries out in-house random checks of the battery cells. All handling and manufacturing processes are designed to avoid wear-inducing stress on the batteries. Apart from battery quality, the energy-saving function is crucial for the service life of low-power electronic devices. RAFI recommends energy-efficient components and optimizes PCB layouts and intended transmission performance. Engineering solutions and high manufacturing quality prevent leakage currents. To protect against electromagnetic interference, RAFI takes suitable EMC precautions, if necessary including shielding.

date: 2021-09-16 | characters: 1416 | download: document, picture 1

RAFI

RAFI Manager Tosberg re-elected as COGD Board Member

Joachim Tosberg, Life Cycle Manager at RAFI, has been re-elected for the second time as a Board Member of the Component Obsolescence Group Deutschland (COGD).

full text

Joachim Tosberg, Life Cycle Manager at RAFI, has been re-elected for the second time as a Board Member of the Component Obsolescence Group Deutschland (COGD). Since 2017, RAFI has been a member of the association, which currently comprises more than 160 companies, and is working there on recommendations for action and guidelines for best-practice solutions in dealing with obsolescence. “The current focus is increasingly on the topic of sustainability”, explains Tosberg. “With the SCIP database, the EU has further tightened the requirements according to RoHS and REACH, obliging manufacturers to report the use of substances of concern in a Europe-wide database. This not only concerns electronic components, but also synthetic materials, metals, paints, and much more. It is therefore all the more important to counteract the accelerated discontinuation of components and materials through proactive selection of the most durable, permanently available materials and components possible. Through our involvement in the COGD, we can help shape the conditions and structures for sustainable obsolescence management in association with other industry players and make product development more resource-efficient overall.” One of the key tasks of COGD, which leading industrial companies as well as numerous component manufacturers and distributors belong to, is to develop strategies and methods for proactive obsolescence management to be able to adapt products and production processes at an early stage where there are discontinued components and make alternatives available. Apart from exchanging information in seminars, workshops and lectures, the association is also involved in standardizing obsolescence management and has introduced Smart-PCN, an overarching standard for the communication and automatic processing of product discontinuations.

date: 2021-08-26 | characters: 1898 | download: document, picture 1

RAFI

A RAFI classic: The KN 19 tactile mains switch for under-membrane installation

Due to its extremely compact design and unique short operating stroke of just 0.55 mm, the KN 19 membrane-covered mains switch from RAFI can be integrated directly into low-profile data entry systems.

full text

Due to its extremely compact design and unique short operating stroke of just 0.55 mm, the KN 19 membrane-covered mains switch from RAFI can be integrated directly into low-profile data entry systems. Therefore, the tactile switches for AC rated voltages of 250 V and DC rated voltages of 12 V to 50 V can replace conventional mains switches without the need for cut-outs in the unbroken overlay. In the case of DC rated voltages, the rated current is 6 A. KN 19 switches are available in a single-pole version with a normally-closed contact plus a normally-open contact and in double-pole form with two normally-open contacts. As an alternative to installation under the overlay, the switch can also be fitted with keycaps from the RAFI RK 90 range. The standard overall height of 9.7 mm means the KN 19 can be combined with other RAFI tactile switches and electronic components on a single PCB. The manufacturer supplies the switches for grid spacing of 19.05 mm x 38.1 mm, also in illuminated types.

date: 2021-06-16 | characters: 1002 | download: document, picture 1

RAFI

E-BOX: Emergency stop type with additional control component

RAFI has extended its E-BOX product family for remote-location emergency stop buttons by a version with an additional control component. Apart from the emergency stop function, the slimline boxes can additionally feature either a pushbutton, a selector button, or a keylock switch from the RAFIX 22 FS+ control component series.

full text

RAFI has extended its E-BOX product family for remote-location emergency stop buttons by a version with an additional control component. Apart from the emergency stop function, the slimline boxes can additionally feature either a pushbutton, a selector button, or a keylock switch from the RAFIX 22 FS+ control component series. This means they offer a further control option for remote applications without the need for extra cables. The housing dimensions of 109 mm x 40 mm x 29 mm make the E-BOX range ideal for attachment to 40-mm profile rails. The mounting clip is easy to attach to the profile rail groove via the single screw hole, then the E-BOX is simply snapped on without the need for tools. Alternatively, two screw holes are available for easy mounting on flat surfaces. RAFI supplies its E-BOX ready for connection. The M12 terminal means the control unit can be put into operation immediately without any need for wiring. The E-BOX comes in IP65 degree of protection and is designed for use in a temperature range of -25°C to +70°C.

date: 2021-06-01 | characters: 1048 | download: document, picture 1

RAFI

RAMO 22 T illuminated pushbutton with metallized front ring

Just like all the control components from the RAMO range from RAFI, the illuminated pushbuttons in the RAMO T series are available for mounting hole diameters of 22.3 mm or 30.3 mm.

full text

Just like all the control components from the RAMO range from RAFI, the illuminated pushbuttons in the RAMO T series are available for mounting hole diameters of 22.3 mm or 30.3 mm. While the RAMO 30 T comes as a standard with stainless steel bezel, RAFI now supplies the slimmer RAMO 22 T models not only in the classic black plastic housing, but also with a metallized front ring. RAMO T models are available in a wide choice of bezel colors. They stand out for uniformly illuminated button surfaces as well as a noticeable tactile feedback. The switching elements are integrated tactile switches from RAFI’s MICON 5 range with high-quality gold contacts, which guarantee switching reliability and a long operating life. For custom legending of the button bezels, RAFI offers the FLEXLAB legending system with labelling sheets either pre-printed or for printing by the customer. Due to their closed mono-housings with IP 66 or higher degree of protection, RAMO control components are ideal for use in or retrofitting into decentral applications. The easy connection via M12 plug terminals makes extra wiring unnecessary and allows installation by untrained personnel.

date: 2021-04-28 | characters: 1169 | download: document, picture 1

RAFI

Signal lamps and control box with IO-Link from RAFI

With new types of its outdoor-capable E-BOX control units and TILTED DIAMOND+ signal lamps, RAFI now offers two innovative product families for the IO-Link interface. As a control box with an IO-Link interface, the E-BOX IO-LINK makes it possible to integrate switches and key switches for simple control tasks in any field bus.

full text

With new types of its outdoor-capable E-BOX control units and TILTED DIAMOND+ signal lamps, RAFI now offers two innovative product families for the IO-Link interface. As a control box with an IO-Link interface, the E-BOX IO-LINK makes it possible to integrate switches and key switches for simple control tasks in any field bus. The slimline, rugged units feature IP65 degree of protection. The M12 terminal means even untrained personnel can quickly install them and put them into operation. The IO-Link device identification prevents errors because incorrectly installed devices are reported to the control unit. The IO-Link Master automatically transfers saved parameters to replacement devices. Thanks to integrated tactile switches from the MICON 5 series, the illuminated pushbuttons of the E-BOX provide excellent tactile feedback. They can be customized via IO-Link with a large range of functions to suit the application. Included among the options are night mode with various brightness levels, the flexible choice of white, red, green, blue, and yellow illumination, or three RGB colors that can be selected by the customer. Furthermore, the buttons can be configured with four different flashing modes for different application cases. RAFI supplies the E-BOX IO-LINK equipped ready for commissioning with one or two switching or indicator elements from the RAFIX 22 FS+ series. For individual marking of the control components, printed or unprinted FLEXLAB labelling sheets are available. With their compact dimensions of 123.2 mm x 40 mm x 35.6 mm, the control units are ideal for assembly on 40 mm profile rails on production lines or safety fences. The accessories include a fixing clip that can be attached to profile rail grooves and other mounting surfaces. The E-BOX simply snaps onto the clip. RAFI has also released an IO-LINK version of its RGB-LED signal lamp from the TILTED DIAMOND+ series. Thanks to its M12 terminal and IO-Link parameterization, it is also fast and easy to install. Apart from freely configurable night settings and illumination colors, the TILTED DIAMOND+ IO-LINK comes with further options. It can signal application-specific alarms or machine statuses with eight different flashing modes such as single flashes, continuous flashing, or pulsating light. What distinguishes the signal lamps are exceptional brightness, vibration resistance with IP66 degree of protection, no need for maintenance, and the striking dome-shaped bezel design. The diamond-shaped lenses arrayed all round give the bezels excellent illumination, clear signal colors, and top visibility over large distances. The accessories available include support tubes in various lengths and shapes and a mounting base.

date: 2021-04-21 | characters: 2730 | download: document, picture 1

RAFI

Rugged signal lamp with stainless steel collar and red/green LED

RAFI is expanding its rugged RAFIX 22 FSR control component range with a signal lamp featuring a stainless steel collar with IP65, IP67 and IP69 degree of protection to the front side. The integrated red/green LED can indicate three signal statuses.

full text

RAFI is expanding its rugged RAFIX 22 FSR control component range with a signal lamp featuring a stainless steel collar with IP65, IP67 and IP69 degree of protection to the front side. The integrated red/green LED can indicate three signal statuses. The translucent indicator is a neutral white in standby mode, green indicates regular operating condition, and red signals faults. The convex signal indicator makes it easy to see the signals from different directions and distances. The lamps have a diameter of 31.3 mm and an installed height of 12.2 mm. Like all RAFIX 22 FS/FSR control and signaling units, they fit standard 22.3 mm installation openings. The mounting depth is 25.45 mm. For the display of different status conditions, the lamps feature wiring over separate terminals with reverse-polarity protection for 2.8 mm x 0.8 mm quick connectors with operating voltages of 8 VDC to 30 VDC.

date: 2021-03-04 | characters: 901 | download: document, picture 1

RAFI

“POWER” now followed by “ULTIMATE”: New High-End ECU for Touchscreens

RAFI uses its own standard ECUs in customer-specific touchscreens and control panels. This has allowed us to quickly realize a large number of projects for industry, agricultural and construction machinery, or medical technology to date, while saving resources.

full text

RAFI uses its own standard ECUs in customer-specific touchscreens and control panels. This has allowed us to quickly realize a large number of projects for industry, agricultural and construction machinery, or medical technology to date, while saving resources. RAFI develops and produces the ECUs and touchscreens including sensors in-house, enabling it to ensure continuous long-term availability and quality of the systems. RAFI covers a wide range of applications with its ECU program. The RAFI control unit in the “ECO-ECU” series with ARM Cortex-A5 or M3M4 processor was developed for simple, cost-sensitive operating and display tasks, with max. 800 x 600 pixel resolution. Control units in the “BALANCE-ECU” model range with a single ARM Cortex-A9 processor cater for higher operating requirements and resolutions of up to 1920 x 1080 pixels. The even more powerful “POWER-ECUs” with ARM Cortex-A9 in Dual or Quad design are used for touch user interfaces with animated graphics and resolutions of up to 1920 x 1200 pixels. With the newest “ULTIMATE-ECU” series, RAFI is raising its range of Embedded Control Units to the next performance level. The “ULTIMATE-ECU” is designed for touchscreen applications with high quality 3D visualization, multi-touch inputs, and Full-HD screen resolutions on up to 24″‚ display diagonals. Its centerpiece is an ARM Cortex-A35, i.MX8QuadXPlus processor from NXP with Yocto-based embedded Linux core and a clock frequency of 900 MHz. As standard, the “ULTIMATE ECU” offers two Gigabit-Ethernet interfaces, a USB 3.0 interface and three CAN-Bus interfaces. The new ECU generation has already been proving its worth as a central computer for mobile processing machines in several projects.

date: 2021-03-04 | characters: 1731 | download: document, picture 1

RAFI

Customized OEM joysticks from RAFI for all control requirements

With its JOYSCAPE joystick platform and extensive add-on options, RAFI is able to implement custom control solutions for any application purpose and with optimum ergonomics for the job.

full text

With its JOYSCAPE joystick platform and extensive add-on options, RAFI is able to implement custom control solutions for any application purpose and with optimum ergonomics for the job. Four differently dimensioned platform modules cover all use cases in various industries such as mechanical engineering, medical technology or construction and agricultural machinery. For heavy-duty applications, RAFI uses its JOYSCAPE ROUGH model with a shock resistance of 110 Nm. Ergonomic multifunction joysticks developed in close cooperation with the customer ensure easy and intuitive operation even under the toughest conditions. For challenging but less rugged applications, the joystick platform offers the versatile JOYSCAPE MULTI basic model. This version is also available with customized handles. Depending on requirements, the manufacturer can install thumb joysticks, rockers, pushbuttons and other actuator or signal elements. Where installation space is tight and control tricky, JOYSCAPE BASIC with free tilt function in the x/y plane is the optimal solution. The smallest model in the range is the compact thumb joystick JOYSCAPE TINY. It is designed for flexible integration into joystick handles or other control elements. All variants use wear-free 3D Hall sensors for motion detection. They have an operating life of up to five million actuation cycles. For high safety requirements, the sensor system is also available in a redundant design. The ferromagnetic steel housing effectively shields the sensor system, providing additional ruggedness. The joysticks are fully manufactured in-house and configured with various rockers, angles of deflection, operating forces or control components. This is how RAFI ensures seamless integration of its products into diverse customer systems. Optional extras are also available such as illuminated handles for work at night, capacitive hand detection to avoid operating errors and easy-clean folding bellows for hygienically sensitive areas.

date: 2021-01-13 | characters: 1992 | download: document, picture 1

RAFI

RAMO S selector switch comes with its own housing

RAFI’s selector switches in the RAMO S series feature a completely closed housing with IP65 degree of protection and M12 terminals. That means they do not need any additional housing.

full text

RAFI’s selector switches in the RAMO S series feature a completely closed housing with IP65 degree of protection and M12 terminals. That means they do not need any additional housing. Therefore, these switches – like all control and indicator elements in the RAMO 22 and 30 series – are ideal for cost-effective construction and retrofitting of decentral applications. Depending on the series, the switches are designed for mounting holes with diameters of 22.3 mm or 30.3 mm. Alternatively, the RAMO EDGE fixing angle offers the option of placing the switches offset on any surfaces or on 40-mm profile rails. The RAMO S series comprises selector switches in different types with rotating angles of 40°, 60° or 90°. Depending on the model, the levers can be switched to up to three positions and the actuation functions momentary contact, latching or momentary contact and latching. The contact functions available are 1NC+1NO, 1NO and 2NO. The rugged selector switches are also available in illuminated versions with translucent handle marking. The simple connection with standard M12 plug terminals makes wiring unnecessary, so RAMO switches, key switches and lamps can even be installed by untrained personnel. The components in the RAMO 22 series feature black front rings in synthetic material, while the RAMO 30 versions have flat stainless steel bezels.

date: 2020-11-06 | characters: 1362 | download: document, picture 1

RAFI

RAFI eCatalog: over 5,000 electro-mechanical components

The RAFI eCatalog is available online at components.rafi.de. The eCatalog presents more than 5,000 electro-mechanical RAFI components divided in the product groups emergency stop, pushbuttons, control components, signal lamps, tactile switches and accessories.

full text

The RAFI eCatalog is available online at components.rafi.de. The eCatalog presents more than 5,000 electro-mechanical RAFI components divided in the product groups emergency stop, pushbuttons, control components, signal lamps, tactile switches and accessories. The completely updated catalog comes with a new user interface and a whole range of new functions. For example, a product finder makes it easy for customers to find the ideal component by entering the parameters they need. For each product, a menu appears next to the technical data and a download option provides an extensive product description including images and videos. There is also a 3D viewer for looking at the product from all angles. The download area provides the 3D data of the selected product in .stp format for import into CAD systems. Users can also find the declarations of conformity as well as operating manuals, certificates and product leaflets there. A wish list allows customers to send product inquiries and receive answers from RAFI distributors. The RAFI eCatalog is available in English, German, French, Italian and Chinese language and was designed for perfect display on desktops, tablets and smartphones.

date: 2020-09-09 | characters: 1197 | download: document, picture 1

RAFI

RAFI illuminated pushbutton in stainless steel design with ring lighting

RAFI has expanded its RAFIX 30 FS+ control component program with illuminated pushbuttons in a modern, stainless steel design. The new models come with ring lighting, a stylish front ring, and a button surface with a metal V2A insert.

full text

RAFI has expanded its RAFIX 30 FS+ control component program with illuminated pushbuttons in a modern, stainless steel design. The new models come with ring lighting, a stylish front ring, and a button surface with a metal V2A insert. The extremely flat structure means the button stands just 3.45 mm proud of the front panel for an elegant appearance. The pushbuttons are available with white, red, green, yellow, or blue lighting rings. The illumination is provided by an LED. The pushbuttons feature IP65 degree of protection to the front side and, like all RAFIX 30 FS+ control and signaling units, they fit standard 30.3 mm installation openings. Even through gloves, the tactile feedback is clear. For terminal connection, the pushbuttons can be combined with PCB switching elements for PCB application or QC switching elements for conventional wiring. The PCB version has a mounting depth of just 15.7 mm, and the switching elements with LEDs and other components are located on a common board. The QC switching elements are connected individually with 2.8 mm x 0.8 mm quick connectors, resulting in a mounting depth of 33.3 mm. Illumination is via a plug-in LED clip. Both types of switching elements are available in versions with gold contacts for a maximum 35 V and 100 mA or with silver contacts for up to 250 V and 4 A.

date: 2020-09-01 | characters: 1332 | download: document, picture 1

RAFI

New RAFI red/green signal indicator

RAFI has expanded its RAFIX 22 FS+ control component program with a signal indicator featuring an integrated red and green LED. The indicator can display three status conditions in one light. The translucent bezel is a neutral white in standby mode, green indicates regular operating condition, and red signals faults.

full text

RAFI has expanded its RAFIX 22 FS+ control component program with a signal indicator featuring an integrated red and green LED. The indicator can display three status conditions in one light. The translucent bezel is a neutral white in standby mode, green indicates regular operating condition, and red signals faults. The indicators have a diameter of 29.8 mm and an installation height of 14.4 mm. The domed surface makes the indicators easily visible also from the side. Like all RAFIX 22 FS+ control and signaling units, they fit standard 22.3 mm installation openings and feature IP65 degree of protection to the front side. The mounting depth is 25.25 mm. The display of different status conditions is possible due to separate terminals with reverse-polarity protection for 2.8 mm x 0.8 mm quick connectors and operating voltages of 8 VDC to 30 VDC.

date: 2020-07-21 | characters: 855 | download: document, picture 1

RAFI

New RAFI signal indicator in elegant design for display of three status conditions

RAFI has expanded its RAFIX 30 FS+ control and signaling unit program with an ultra-flat (3.45 mm) LED signal indicator featuring a stainless steel front ring. Thanks to an integrated red and green LED, the indicator can signal three status conditions.

full text

RAFI has expanded its RAFIX 30 FS+ control and signaling unit program with an ultra-flat (3.45 mm) LED signal indicator featuring a stainless steel front ring. Thanks to an integrated red and green LED, the indicator can signal three status conditions. The translucent bezel is a neutral white in standby mode, green indicates regular operating condition, and red signals faults. The signal indicator features separate terminals with reverse-polarity protection for 2.8 mm x 0.8 mm quick connectors and operating voltages of 8 VDC to 30 VDC. The new signal lamps feature IP65 degree of protection to the front side and, like all RAFIX 30 FS+ control and signaling units, they fit standard 30.3 mm installation openings. With a collar diameter of 34.5 mm and a mounting depth of 31.85 mm, the integrated lamps are suitable for a minimum grid spacing of 35 mm.

date: 2020-07-01 | characters: 858 | download: document, picture 1

RAFI

New RAFI illuminated pushbutton with ring lighting

RAFI has expanded its RAFIX 22 FS+ control and signaling units program with illuminated pushbuttons with ring lighting. The pushbuttons come with an illuminated ring in the colors white, red, green, yellow, or blue, which makes them also suitable for night design. The illumination of the ring is provided by an LED.

full text

RAFI has expanded its RAFIX 22 FS+ control and signaling units program with illuminated pushbuttons with ring lighting. The pushbuttons come with an illuminated ring in the colors white, red, green, yellow, or blue, which makes them also suitable for night design. The illumination of the ring is provided by an LED. The pushbuttons feature IP65 degree of protection to the front side, an installation height of just 10 mm and, like all RAFIX 22 FS+ control and signaling units, they fit standard 22.3 mm installation openings. The pushbuttons deliver clear tactile feedback, even through gloves. For terminal connection, the pushbuttons can be combined with PCB switching elements for PCB application or QC switching elements for conventional wiring. The PCB version has a mounting depth of just 9.2 mm, and the switching elements with LEDs and other components are located on a common board. The QC switching elements are connected individually with 2.8 mm x 0.8 mm quick connectors, resulting in a mounting depth of 27 mm. Illumination is via a plug-in LED clip. Both types of switching elements are available in versions with gold contacts for a maximum 35 V and 100 mA or with silver contacts for up to 250 V and 4 A.

date: 2020-05-27 | characters: 1222 | download: document, picture 1

RAFI

Control units for respirators: RAFI ramps up production

HMI specialist RAFI has been producing capacitive control units for the HAMILTON-C6 mobile respirator station from Swiss medical technology manufacturer Hamilton Medical for around four years.

full text

HMI specialist RAFI has been producing capacitive control units for the HAMILTON-C6 mobile respirator station from Swiss medical technology manufacturer Hamilton Medical for around four years. This company, which has specialized since 1983 in the development of intensive respirator systems, ranks among the leading suppliers of intelligent high-end devices. Currently, manufacturers and suppliers face major challenges due to the coronavirus pandemic and the resulting surge in demand for respirators. But, thanks to foresighted planning and management of manufacturing capacities, RAFI has succeeded in increasing production of its control units far beyond the usual volumes. “As soon as the first alarming reports came in, we started thinking about how we could boost delivery capacity if necessary,” explains Max Mattes, the responsible RAFI Account Manager for the Systems business unit. “Our Purchasing department pro-actively contacted the relevant component suppliers. Our control units are an essential feature of the respirators. So of course we feel that RAFI has an indirect responsibility for ensuring the supply of life-saving medical devices.” The HMI manufacturer produces the control units entirely in-house. To increase the quantities at short notice, it had to flexibly adjust capacities in its production department and re-organize its order processing. The year before last, the company established its own clean room system for the production of glass sensors for capacitive touchscreens so that it could remain independent from Asian suppliers. Apart from the 17″ touch sensors for the Hamilton respirators, RAFI also produces the diagnostic electronics and integrates the touch controllers on its own assembly lines. The front glass panels are also printed and fitted with electro-mechanical keypads in RAFI’s own facility. The hygiene-compliant silicon key switches are inserted into openings cut into the front glass panels, and snap-action contacts are installed underneath the actuators. Development and production of the control units, which RAFI supplies as fully assembled, ready-to-use assemblies, comply with the EN ISO 13485 medical standard. “To meet the acute demand, we had to restructure a lot of our sequences. Obviously, all processes that are critical for the operating surfaces of the respirators come first right now,” says Mattes. “But of course we’re still doing everything to make sure all our customers get their supplies on time.”

date: 2020-05-07 | characters: 2478 | download: document, picture 1

RAFI

Robust USB 3.0 and RJ45 feedthroughs for integrated and standalone setups

The RAFI RAMO range includes robust USB 3.0 and RJ45 feedthroughs for front panel installation or standalone setups, in addition to switches and signal lamps with M12 plug terminals. The RAMO F feedthroughs feature an IP65 degree of protection when the protective cap is closed.

full text

The RAFI RAMO range includes robust USB 3.0 and RJ45 feedthroughs for front panel installation or standalone setups, in addition to switches and signal lamps with M12 plug terminals. The RAMO F feedthroughs feature an IP65 degree of protection when the protective cap is closed. RAMO EDGE 90° mounting angles allow for remote mounting of individual feedthroughs and other RAMO components on vertical surfaces or on 40-mm profile rails. RAFI especially designed all RAMO 22 and 30 components for individual housing-free mounting at remote locations. Featuring single-part, fully enclosed mono-housings, the feedthroughs can be installed in 22.3 mm or 30.3 mm mounting holes without an additional housing, just like the series‘ pushbuttons, emergency stop switches, selector switches, keylock switches, and LED signal lamps. RAMO 22 components feature black plastic front rings. RAMO 30 versions have a flat stainless-steel bezel.

date: 2020-01-09 | characters: 928 | download: document, picture 1

RAFI

RAMO K: Keylock switch with M12 terminal for stand-alone assembly

The keylock switches from RAFI’s RAMO K range offer a rugged, fast-assembly control solution for decentralized applications where it is necessary to lock critical actuation functions. Like all control elements and indicators from the RAMO program, the keylock switches do not require any additional installation housing.

full text

The keylock switches from RAFI’s RAMO K range offer a rugged, fast-assembly control solution for decentralized applications where it is necessary to lock critical actuation functions. Like all control elements and indicators from the RAMO program, the keylock switches do not require any additional installation housing. The completely closed housing with IP65 degree of protection and the M12 terminal ensure rapid on-site assembly without time-consuming manual wiring. Thanks to the Plug&Play connection via standard M12 plug terminals, even untrained personnel can commission the devices from the RAMO 22 and RAMO 30 series for 22.3 mm or 30.3 mm mounting holes. With the RAMO EDGE 90° mounting angle for individual mounting, the switches can also be mounted as required on any vertical surface and on 40-mm profile rails. RAFI supplies the RAMO K keylock switches in a variety of types with rotating angles of 40°, 60°, or 90° as well as various rotating angle shapes. The switches are also available with distinctive haptic qualities for up to three switching positions with momentary contact, latching, or combined actuating functions. The RAMO 22 and 30 models differ not only in their dimensions, but also in design, with black front rings made of synthetic material or flat stainless-steel front rings. RAFI presents the RAMO range of operating and indicating elements as well as feedthroughs at www.rafi.de/en/ramo-2230.

date: 2019-12-04 | characters: 1430 | download: document, picture 1

RAFI

Leading-edge control solutions from RAFI

RAFI exhibited its developments and products in the field of control components, system components, and capacitive input technologies at the 2019 SPS trade show in Nuremberg, Germany. Introducing Smart Solutions, RAFI presented a new technology concept for wireless condition and progress signaling for use in intralogistics processes.

full text

RAFI exhibited its developments and products in the field of control components, system components, and capacitive input technologies at the 2019 SPS trade show in Nuremberg, Germany. Introducing Smart Solutions, RAFI presented a new technology concept for wireless condition and progress signaling for use in intralogistics processes. The portal-based system intelligently links mobile pushbutton units with freely positionable signal lamps via WiFi. What makes Smart Solutions stand out are the universal application options, simple use, and fast setup. The pushbutton boxes and signal lamps integrate WiFi interfaces. The units come with an unambiguous ID and a USB port connector. To start up the system, the user simply logs in to the RAFI portal once, defines the linking logic required, and saves a digital twin of its application. Another RAFI highlight at the trade fair was a representative cross-section of the company’s solutions for renowned customers in machine and plant engineering, automotive and commercial vehicle manufacturing, communications electronics, and household appliances. The product range on show covered everything from handheld units and operating panels to electronic assemblies and fully integrated complete solutions for commercial vehicle control. RAFI is not only one of Germany’s largest contract manufacturers of electronics, but also ranks among Europe’s leading manufacturers of capacitive industrial touchscreens. With its Twin Touch technology, RAFI has launched a new generation of industrial touch data entry systems featuring combined touch and force detection. This solution prevents accidental input errors and opens up scope for new input levels. It means users can select or set function menus or parameters by varying the pressure exerted on the display. Another innovation, the mechanical key switches and finger guidance solutions in the FLEXSCAPE range enable reliable blind operation of touchscreen functions. The touchscreen keeps its high degrees of resilience and ingress protection because the actuators are fixed without openings or holes in the surface. Other areas of the trade fair stand were dedicated to compact embedded control units (ECU) for HMIs and control systems, new basic models for the JOYSCAPE joystick platform, and RAFI’s successful switch and key switch programs.

date: 2019-12-04 | characters: 2342 | download: document, picture 1

RAFI

TwinTouch industrial touchscreens with force detection

RAFI expands its GLASSCAPE portfolio of industrial-grade capacitive touchscreens, introducing the new TwinTouch input technology, which in addition to touch evaluates the force of inputs. Combining touch and force detection, TwinTouch significantly increases operational safety.

full text

RAFI expands its GLASSCAPE portfolio of industrial-grade capacitive touchscreens, introducing the new TwinTouch input technology, which in addition to touch evaluates the force of inputs. Combining touch and force detection, TwinTouch significantly increases operational safety. Capacitive switches and fields in the touchscreen can be configured to require a defined pressure force for touch commands. This helps prevent accidental input through unintended contact with the screen. The switching thresholds for the applied pressure can be individually adjusted via software. At the same time, the combined evaluation of touch and mechanical force enables an implementation of additional input levels. For instance, pressing a screen button for a prolonged time may activate a context menu, or applying different amounts of pressure may be used to adjust parameter values. The TwinTouch system with trackless pressure measurement ensures reliable IP65 ingress protection. Video clip: https://www.youtube.com/watch?v=r5dRQgXlDsc Deep link: https://www.rafi.de/en/products/control-systemshmi/capacitive-systemsglasscape/ PDF brochure: https://www.rafi.de/en/company/download-center/pdf-brochures-flyers/

date: 2019-11-19 | characters: 971 | download: document, picture 1

RAFI

Agritechnica: Operating solutions for agricultural machinery and commercial vehicles

RAFI presents its innovative control components and operating solutions for agricultural machinery and commercial vehicles at the 2019 Agritechnica trade show in Hanover, Germany, in Hall 17, at Booth B19.

full text

RAFI presents its innovative control components and operating solutions for agricultural machinery and commercial vehicles at the 2019 Agritechnica trade show in Hanover, Germany, in Hall 17, at Booth B19. The HMI specialist particularly highlights armrest systems developed for VALTRA tractors and PistenBully snow plows, the extended JOYSCAPE joystick platform, the new touchscreen input technology TWIN TOUCH, the RAFIX 22 FSR series of control and signal components, and the RAMO pushbutton series. Trade show visitors are welcome to test the SmartTouch armrest of current VALTRA tractors in an agricultural simulator. This integrated control system, manufactured entirely by RAFI and awarded with the Red Dot Design Award for its ergonomics, allows operators to customize all functions. As further proof of its development competence, RAFI presents the armrest control panel designed for the Kässbohrer PistenBully. Both the innovative multifunction lever and the four-axis joystick for controlling the snow plow blade are based on RAFI’s JOYSCAPE joystick platform, which enables speedy customization of levers and joysticks for all kinds of applications and with varying degrees of complexity. Additional showcases include a joystick for the latest generation of Fendt tractors and the new elementary component JOYSCAPE TINY, an extremely compact thumb joystick for space-saving integration into joystick handles. RAFI’s new TWIN TOUCH input technology is an innovation in the field of PCAP touchscreens for mobile machinery. It combines touch and force detection, preventing accidental incorrect input and enabling new safety and input functions. There is a working model at the booth, which visitors are invited to try out themselves. RAFI furthermore exhibits electronic assemblies that the company produces as an EMS service provider for manufacturers of mobile machinery and industrial vehicles. Also on display, RAFIX 22 FSR control and signal components boast high thermal resistance, high resistance to dirt and dust, and tolerate cleaning with high-pressure cleaners. To complete the selective overview of RAFI’s extensive portfolio, RAMO pushbuttons are especially suited for easy integration in offset applications and require no additional housing. Visit RAFI at the 2019 Agritechnica exhibition! Hanover, Germany, 10 – 16 November 2019 Hall 17, Booth B19

date: 2019-11-11 | characters: 2266 | download: document, picture 1

RAFI

Emergency stop switches with M12 plug terminals

Complementing the tried-and-tested pushbuttons, selector switches, keylock switches, and LED signal lamps, RAFI also supplies emergency stop switches in its RAMO product range. RAMO E switches are designed for 22.3 mm and 30.3 mm mounting hole diameters.

full text

Complementing the tried-and-tested pushbuttons, selector switches, keylock switches, and LED signal lamps, RAFI also supplies emergency stop switches in its RAMO product range. RAMO E switches are designed for 22.3 mm and 30.3 mm mounting hole diameters. They feature two NC contacts for a 35 V switching voltage and comply with all relevant ISO and IEC standards. The design ensures simple, time-saving installation. Like all RAMO devices, the emergency stop switches feature easy-assembly M12 plug terminals that require minimum wiring work. Customers can specify any cable length from the manufacturer of their choice for the plug & play solution that guarantees easy commissioning, even by untrained personnel. The RAMO series‘ hallmark single-part, fully enclosed mono-housings can be mounted directly on aluminum profile rails using the RAMO EDGE mounting bracket. No additional housing is necessary. This makes RAMO operating components a flexible, highly economical standalone solution for distributed industrial applications. All RAMO emergency stop switches provide IP65 ingress protection according to DIN EN 60529 on the front side. Featuring maximum mounting depths of 30.2 mm (RAMO 22 E) or 36.4 mm (RAMO 30 E), they are also suitable for applications with restricted space. The RAMO series is designed to fit the look and dimensions of the RAFIX FS+ series, allowing users to mix and match control components from both series as they wish. Data for RAMO E – including stp files for import into CAD systems – are available at https://components.rafi.de.

date: 2019-10-30 | characters: 1566 | download: document, picture 1

RAFI

Powerful Linux control unit for RAFI touch operating panels

RAFI offers customization of its GLASSCAPE touch displays and control panels with complete processor units for control and visualization tasks. Using its own embedded control units (ECU), the HMI specialist ensures the time-saving and efficient implementation of customer projects in industrial, automotive, and medical applications.

full text

RAFI offers customization of its GLASSCAPE touch displays and control panels with complete processor units for control and visualization tasks. Using its own embedded control units (ECU), the HMI specialist ensures the time-saving and efficient implementation of customer projects in industrial, automotive, and medical applications. Device manufacturers thus receive complete, ready-to-install touch control solutions including housings and drivers from a single source. Three performance classes cover the entire range of requirements: the ECO-ECU series offers cost-optimized solutions for simple control and display tasks. BALANCE-ECU units support touch displays with resolutions up to 800 x 600 pixels and are suitable for displaying animated graphics. The most powerful unit, POWER-ECU, supports high-quality 3D visualizations, multitouch input, and full HD screen resolution for display diagonals up to 24″. The necessary computing power comes from the integrated ARM Cortex-A9 clocked at 800 MHz, complemented by 1 GByte DDR3 SDRAM and 1 GByte NAND flash memory. The long-lasting POWER-ECUs are now also available with a Yocto-based embedded Linux operating system as an alternative to Windows Embedded Compact 2013 or 7. Users benefit from optimized hardware controls, secure integration of control systems into their own applications, and RAFI’s commitment to provide tweaks and continuous software maintenance. In addition, the inherent advantages of the Linux environment include transparency and ongoing development of the kernel by a global community. The POWER-ECU units are designed as plug-in modules for a baseboard with a scalable periphery, supplied by RAFI with custom form factor, customer-specified interfaces, and all necessary drivers. RAFI also offers POWER-ECU evaluation kits for customers seeking to develop their own applications.

date: 2019-10-09 | characters: 1860 | download: document, picture 1

RAFI

Tactile control elements for blind operation of industrial touchscreens

RAFI provides tactile control solutions for its GLASSCAPE industrial touchscreens in applications that require the operator’s constant attention. The innovative FLEXSCAPE ONE and FLEXSCAPE WHEEL control elements are integrated directly into the touchscreen surface, enabling safe blind operation.

full text

RAFI provides tactile control solutions for its GLASSCAPE industrial touchscreens in applications that require the operator’s constant attention. The innovative FLEXSCAPE ONE and FLEXSCAPE WHEEL control elements are integrated directly into the touchscreen surface, enabling safe blind operation. The FLEXSCAPE ONE pushbutton is used for tactile switching. It is activated by touch and requires a threshold pressure to trigger actuation. Actuation is confirmed by distinctive haptic and acoustic feedback. The FLEXSCAPE WHEEL rotary button enables users to select functions or set parameters according to context. Featuring regular indentations, the circular finger guidance provides haptic orientation without looking. Due to their compatible geometries, both control elements can also be combined into one element covering all functions for additional operating safety. For example, customers can specify that functions or values selected by wheel must be confirmed by pressing the button. RAFI equips its touchscreens with several FLEXSCAPE elements anywhere on the closed glass surface according to customer specifications. The touchscreen keeps its high degrees of resilience and ingress protection, since the actuators are fixed without cut-outs or holes in the surface. Additional diagnostic electronics are not required. Needing no elaborate surface preparation, FLEXSCAPE models are a low-cost alternative to milled contours.

date: 2019-09-18 | characters: 1434 | download: document, picture 1

RAFI

Compact, highly reliable pushbuttons and Emergency Stop buttons

RAFI’s LUMOTAST 16 pushbuttons and illuminated pushbuttons for 16.2 mm mounting holes are especially suitable for handheld control devices, or any application that requires robust switch functions in a low profile. They are very compact and provide distinct haptic feedback.

full text

RAFI’s LUMOTAST 16 pushbuttons and illuminated pushbuttons for 16.2 mm mounting holes are especially suitable for handheld control devices, or any application that requires robust switch functions in a low profile. They are very compact and provide distinct haptic feedback. The series offers various design options and allows for individual labeling, to create appealing customer-specific user interfaces. LUMOTAST 16 pushbuttons have an external diameter of only 22.3 mm and fit in 25 mm x 25 mm arrays. They take up very little space inside the housing, featuring a mounting depth of only 18 mm. Complementing the (illuminated) pushbutton range, the series also includes different types of Emergency Stop pushbuttons: an innovative active/inactive version for detachable or wireless control units has a translucent plastic mushroom head that lights up red when properly connected to the Emergency Stop function of the machine/system. When inactive, the mushroom is colorless and cannot be mistaken for an E-Stop according to DIN EN ISO 13850. The second alternative in the series are conventional Emergency Stop pushbuttons with one or two NC contacts or two NC and one NO contact. Installing the devices takes mere seconds: once inserted into the mounting hole, they are attached by a single threaded nut behind the housing front panel. They can easily be connected via 2.8 x 0.5 mm quick-connect terminals. Bezels are available in six colors according to EN 60073, to clearly show what function has been assigned to a switch. The C-LAB variant additionally offers colored or metallized front rings. C-LAB legend inserts and bezels allow for customer-specific labeling of the pushbuttons. RAFI can also supply LUMOTAST 16 pushbuttons with customer-specific printing upon request. The switch contacts utilize high-quality gold contacts to ensure precise switching in harsh environments in the long term. Emergency Stop pushbuttons for large currents are available with silver contacts. All pushbuttons and E-Stops feature IP65/IP67 ingress protection.

date: 2019-07-31 | characters: 2053 | download: document, picture 1, picture 2

RAFI

bauma trade fair: Custom-tailored operating systems for mobile machinery

At the 2019 bauma trade fair in Munich, Germany, RAFI (Hall A2, Booth 432) showcases customer-specific operating, monitoring, and control systems, as well as control components for construction and agricultural machinery, municipal vehicles, and forklifts.

full text

At the 2019 bauma trade fair in Munich, Germany, RAFI (Hall A2, Booth 432) showcases customer-specific operating, monitoring, and control systems, as well as control components for construction and agricultural machinery, municipal vehicles, and forklifts. Exhibits include operating panels for wheel loaders, concrete mixers, and forklifts, a robust display module for road rollers, and a snowplow input and control interface for controlling the blade, gritter, and sprayer. Two custom-tailored armrests demonstrate RAFI’s advanced design capabilities for highly integrated control technology. The SmartTouch armrest developed for a Finnish tractor manufacturer won the Red Dot Award for its ergonomic design. It contains an innovative multifunctional drive stick that enables optional full manual control of all vehicle movements otherwise controlled by pedals. Operators can individually adapt all control and operating functions via a touchscreen installed at the front end of the armrest. The second armrest shown at bauma, is used in Pistenbully snow groomers. RAFI not only integrated various sturdy, durable buttons and command devices from its extensive portfolio, but also a four-axis joystick that controls the blade movement with all degrees of freedom. This armrest is designed to withstand extreme ambient temperatures ranging from -40 °C to +80 °C.

date: 2019-03-21 | characters: 1363 | download: document, picture 1

RAFI

Lothar Seybold new RAFI CEO

A new generation of leadership will be guiding HMI specialist RAFI GmbH into a digital future. Long-time managing directors Albert Wasmeier and Gerhard Schenk will leave their executive positions and join the RAFI board of directors in the second half of 2019. Dr. Lothar Seybold ….

full text

A new generation of leadership will be guiding HMI specialist RAFI GmbH into a digital future. Long-time managing directors Albert Wasmeier and Gerhard Schenk will leave their executive positions and join the RAFI board of directors in the second half of 2019. Dr. Lothar Seybold, who has held various high-level management positions at RAFI for more than 10 years, has been named the new CEO and technical director at the beginning of this year. His principal goal as RAFI CEO is to make the company more digital across the board, while keeping it focused on the physical requirements of the design and function of modern operating technology. Seybold holds a doctorate in electronics engineering, an MBA, Master of Business Administration (University of Wuerzburg), and a PhD in control technology (University of Zielona Gora). He began his career at RAFI as a product manager for operating systems. In 2013, Seybold became the head of system development. In 2016, he was promoted to head of the Components and Systems business units, and focused the company on innovation management, new technologies, and improving overall customer satisfaction. Seybold has extensive international experience, having worked as a project engineer and consultant in New Zealand and Switzerland. Before joining RAFI, he worked at the software company is Integrated Systems AG, Radolfzell. Seybold is also a passionate skier.

date: 2019-03-21 | characters: 1409 | download: document, picture 1

RAFI

RAFI manufactures SmartTouch armrest for Valtra tractors

RAFI manufactures SmartTouch armrest for Valtra tractorsGerman electronics manufacturer RAFI worked in close cooperation with the Finnish tractor manufacturer Valtra to design SmartTouch armrests with a completely new multifunction drive lever for the new N, S, and T Valtra tractor series.

full text

RAFI manufactures SmartTouch armrest for Valtra tractors German electronics manufacturer RAFI worked in close cooperation with the Finnish tractor manufacturer Valtra to design SmartTouch armrests with a completely new multifunction drive lever for the new N, S, and T Valtra tractor series. The armrest integrates all of the components for controlling Valtra’s agricultural machinery. This innovative, highly ergonomic design won the 2017 Red Dot Design Award. The smart armrest is an integral part of Valtra’s novel operating concept allowing drivers to customize the functionality of the controls in their cab. At the front end, the armrest features a touch screen with an interactive 3D representation of the tractor. Operators can select all vehicle functions by tapping on the model. They can set output ranges and numbers of revolutions via virtual slide controllers and, through a simple touch or swipe, assign functions to control elements according to their preferences. This includes the hydraulic system and all valves to operate front and rear loaders. Functions that are not needed can be disabled to prevent errors and ensure intuitive operation. All configurations are automatically saved and can be managed in any number of user profiles. RAFI manufactures the complete armrests including the housing and supplies them as ready-to-connect units with plug-and-play connectors. The multifunctional drive lever, the integrated thumb joystick, and the separate joystick for hydraulic control are based on RAFI’s JOYSCAPE platform of customizable joysticks. RAFI designed form, function, and colors to Valtra’s specifications. A handrest with an injection-molded soft rubber coating offers a comfortable, slip-proof hold. RAFI also integrated its own short-travel keyswitches and was thereby able to control the quality through in-house manufacturing. The drive lever and safely isolated sliders in the control panel are equipped with noncontact, wear-free Hall sensors with a service life that tests beyond five million operating cycles. These controls are used for continuous adjustment of the idle running mode and the rear loader. RAFI used short-travel keyswitches from its MICON 5 series for the membrane keyboard and pushbuttons and integrated redundant MICON variants for safety-critical functions. Furthermore, RAFI designed concave and convex bezels especially for Valtra. These enable easy haptic recognition of frequently used hard-key functions. „We do not impose a ready-made design on customers“, says Eduard Janez, Global Key Account Manager at RAFI. „They are able to adapt the system to their needs and freely assemble the components. This enables our customers to realize their design ideas and develop intuitive ruggedized interface controls that improve the operator experience.“ Company background RAFI group Founded in 1900, RAFI now develops and produces electromechanical components such as pushbuttons and switches, operating systems such as touch screens, keyboards, electronic components, and systems for man-machine communication. RAFI products are employed in more than 30 industries, e.g., in medical equipment, mechanical engineering, road and railway vehicles, household appliances, and telecommunications. The RAFI group operates internationally with approx. 2,500 employees at ten sites in Germany, Europe, China, and the USA. The group’s headquarters are located in Berg (Baden-WĂĽrttemberg, Germany). ??

date: 2019-02-20 | characters: 2754 | download: document, picture 1, picture 2

RAFI

embedded world exhibition: EMS, embedded ECUs, first touchscreen with force detection

HMI specialist RAFI presents its latest technologies at the 2019 embedded world exhibition in Nuremberg, Germany, Hall 3, Stand 541. The company’s subsidiary RAFI ELTEC shows new applications and technologies from its EMS (Electronics Manufacturing Services) portfolio.

full text

HMI specialist RAFI presents its latest technologies at the 2019 embedded world exhibition in Nuremberg, Germany, Hall 3, Stand 541. The company’s subsidiary RAFI ELTEC shows new applications and technologies from its EMS (Electronics Manufacturing Services) portfolio. RAFI’s innovations include the TwinTouch touchscreen technology, which detects not only touch but also the intensity of pressure exerted on the panel. Combined touch and force detection prevents false inputs, increases operating security, and makes additional input levels feasible. Customized development of operating systems with capacitive touch displays is another RAFI highlight. Showcases in this segment include the Smart Pad 2.0 panel for Kuka robot systems as well as a premium-quality control panel for Schaerer coffee machines. Complementing these, RAFI also presents embedded control units. These ECUs can be used in operating solutions for various control and visualization tasks. This range has most recently been expanded by the Linux-based POWER-ECU control unit, which supports high-quality 3D visualizations as well as multi-touch inputs and full HD screen resolutions for displays up to 24″. EMS provider RAFI ELTEC develops and manufactures electronic assemblies and systems according to customer-specific requirements, starting from the idea all the way to the finished product. RAFI’s subsidiary specializes in robust embedded wireless and controller solutions for all common transmission standards such as Wi-Fi, GSM-GPRS/UMTS/LTE, ZigBee, 6LowPan, LLC, Bluetooth, and other wireless technologies. The customized implementation of embedded control units is also part of RAFI ELTEC’s scope of services. Meet RAFI and RAFI ELTEC at the 2019 embedded world exhibition in Hall 3, Stand 541.

date: 2019-02-06 | characters: 1693 | download: document, picture 1

RAFI

RAMO standalone industrial controls and indicators with M12 connectors

Complex wiring and properly sealed, dedicated enclosures often drive up the cost of fitting industrial applications with pushbuttons, function switches, E-Stops, or signaling devices. The RAMO line of control components and signal lamps provides highly economical and easy-to-install alternatives.

full text

Complex wiring and properly sealed, dedicated enclosures often drive up the cost of fitting industrial applications with pushbuttons, function switches, E-Stops, or signaling devices. The RAMO line of control components and signal lamps provides highly economical and easy-to-install alternatives. These standalone RAFI products need no extra housings or special gaskets, and they are plug-and-play ready, reducing costly wiring time and precluding mistakes. Even untrained personnel can install the devices. Due to their single-piece, fully enclosed mono-housings and connection via M12 circular plug connectors, RAMO pushbuttons, emergency stops, selector switches, key switches, and LED signal lamps can be installed in standard 22.3 mm and 30.3 mm mounting holes without any additional sealing. The RAMO EDGE 90° mounting bracket enables quick mounting of standalone RAMO components. The bracket fits on 40 mm profile rails. Depending on the type of RAMO component, the installation depth varies between 30.2 mm (RAMO 22) and 36.4 mm (RAMO 30). For applications with restricted space, devices are available with M12 connectors featuring angled cable exits. Rotated by 135°, these cable exits allow for a high packing density. The RAMO series is designed to fit the look and dimensions of the RAFIX FS+ series, allowing users to mix and match control components from both series as they wish. The pushbuttons are available with fully illuminated bezels in many different colors and with a normally open contact. The pushbuttons can be individually labeled using the FLEXLAB system. In addition to pushbuttons, function switches, and LED lamps in five colors, the RAMO range also includes USB 3.0 and RJ45 bushings that feature the same design. A product video at https://www.youtube.com/watch?v=LO5Wcbx5eL0 presents application examples and installation variants for the RAMO series.

date: 2019-01-31 | characters: 1884 | download: document, picture 1, picture 2

RAFI

Compact Emergency Stop button

The new LUMOTAST 22 is the first Emergency Stop button from RAFI’s LUMOTAST range for 22.3 mm mounting holes. Featuring a compact size and a low installation depth of 17.6 mm, this pushbutton is very useful whenever space above or below the front panel is limited.

full text

The new LUMOTAST 22 is the first Emergency Stop button from RAFI’s LUMOTAST range for 22.3 mm mounting holes. Featuring a compact size and a low installation depth of 17.6 mm, this pushbutton is very useful whenever space above or below the front panel is limited. The actuating element is designed to protect the Emergency Stop button against blocking by foreign objects, with its positively driven mechanism that is tamper-proof in keeping with DIN EN ISO 13850. LUMOTAST 22 versions are available with two NC or two NO contacts, or with one NO and one optional signaling contact. In addition, customers can select models sporting a night-time design with illuminated arrows showing how to release the buttons. The switching elements with silver contacts are designed for 250 V voltage and 2.5 A switching current. They provide IP65 ingress protection. The E-Stops can be installed in seconds, inserting easily into the mounting hole and secured in place by a single threaded nut behind the housing front panel. The pushbuttons are connected via 2.8 x 0.8 mm quick connectors. Alternatively, wires can be soldered to the switch contacts. Company background RAFI group Founded in 1900, RAFI now develops and produces electromechanical components such as pushbuttons and switches, operating systems such as touch screens, keyboards, electronic components, and systems for man-machine communication. RAFI products are employed in more than 30 industries, e.g., in medical equipment, mechanical engineering, road and railway vehicles, household appliances, and telecommunications. The RAFI group operates internationally with approx. 2,500 employees at ten sites in Germany, Europe, China, and the USA. The group’s headquarters are located in Berg (Baden-WĂĽrttemberg, Germany).

date: 2018-12-05 | characters: 1139 | download: document, picture 1

RAFI

Customized heavy-duty joysticks

Adding to the already versatile JOYSCAPE platform, RAFI is now offering heavy-duty joysticks for outdoor machines and other applications in which control components must meet extremely demanding requirements. The platform concept enables a robust standard design base to be combined with customized multi-function joysticks.

full text

Adding to the already versatile JOYSCAPE platform, RAFI is now offering heavy-duty joysticks for outdoor machines and other applications in which control components must meet extremely demanding requirements. The platform concept enables a robust standard design base to be combined with customized multi-function joysticks. RAFI integrates buttons, rocker switches, thumb joysticks, rotary encoders, and LEDs as required. Employing wear-free noncontact electronic 3D Hall sensors for motion detection, the new heavy-duty joystick variant achieves a long operation lifetime even in the most demanding applications. It is built to sustain 5 million operating cycles even in extreme conditions and at environmental temperatures between -40 °C and +85 °C. The joystick has 110 Nm impact strength in X and Y direction. It handles pressure up to 1000 N and tensile loads up to 500 N in Z direction. The ferromagnetic, high-alloy steel housing effectively shields the sensor system for added ruggedness. The sensors are designed redundantly for superior reliability and safety. Due to its high center of rotation and large 20° tilt angle, the joystick only needs a small, 65 mm wide mounting hole. This particular design provides for very comfortable operation. In addition, it is suitable for bellows with a minimum of folds, which makes this an easy-to-clean solution. The joystick is very compact, featuring a mounting depth of only 50 mm and 77 x 77 mm flange dimensions. Company background RAFI group Founded in 1900, RAFI now develops and produces electromechanical components such as pushbuttons and switches, operating systems such as touch screens, keyboards, electronic components, and systems for man-machine communication. RAFI products are employed in more than 30 industries, e.g., in medical equipment, mechanical engineering, road and railway vehicles, household appliances, and telecommunications. The RAFI group operates internationally with approx. 2,500 employees at ten sites in Germany, Europe, China, and the USA. The group’s headquarters are located in Berg (Baden-Württemberg, Germany).

date: 2018-11-21 | characters: 1469 | download: document, picture 1

Agro DE EN
AIRTEC DE
AutoVimation DE EN
BI-BER DE
Biesse DE
CONTA-CLIP DE EN
EGE DE EN
Excelitas Technologies Corp. DE EN
FIBOX DE EN
Fluke Process Instruments DE EN
Gossen Metrawatt GmbH DE EN
GRIESSBACH DE
HECHT DE
INELTA DE EN
Kaiser DE
LOSYCO DE EN
MENZEL DE EN
MEZ DE EN
MKT DE
PiL DE EN
RAFI DE EN CN
SEIFERT DE EN
Tegon DE
Vision Components DE EN

ALLE KUNDEN   DE | EN | CN
